Guardian Fall Protection 20075 Vertical Lifeline Rope 50 Ft

Product Description

The GUARDIAN FALL PROTECTION 20075 is a 5/8-inch vertical lifeline rope, 50 feet in length, fitted with a steel thimble eye and sewn termination at the top. The thimble eye design allows connection via shackle or carabiner in rigging situations where a standard snap hook lifeline cannot be used. The rope is constructed in yellow for high visibility and is intended for use as a vertical lifeline component in a complete fall arrest system. Licensed OSHA-aware fall protection installers and safety riggers select this line for compliant overhead anchorage setups on construction and general industry jobsites.

This lifeline is suited for vertical lifeline applications in both construction and general industry environments where OSHA 1926.502 and 1910.140 compliance is required. The shackle or carabiner connection method makes it adaptable to anchorage points that cannot accept snap hook terminations. When paired with a compatible 5/8-inch rope grab, the 20075 functions as a complete vertical lifeline assembly, providing a continuous fall arrest travel path for workers ascending or descending vertical structures such as towers, ladders, and scaffolding.

Key Features

• 5/8-inch diameter yellow rope provides high visibility and compatibility with standard 5/8-inch rope grabs
• Steel thimble eye protects the rope termination loop from wear and deformation under load
• Sewn termination construction at the thimble eye for a secure, factory-finished connection point
• Connects via shackle or carabiner where snap hook lifelines cannot be rigged
• 50-foot length covers typical vertical travel distances on towers, ladders, and elevated structures
• Designed to support OSHA 1926.502 and 1910.140 vertical lifeline duty requirements

Compatibility

Designed for use as a vertical lifeline when paired with a compatible 5/8-inch rope grab as part of a complete fall arrest system meeting OSHA 1926.502 and 1910.140 requirements.

Installation Notes

Installation and rigging of vertical lifelines must be performed by a competent person as defined by applicable OSHA standards. Secure the thimble eye to a rated overhead anchorage point using an appropriate shackle or carabiner; verify all hardware is rated for the intended load before use. De-rig and remove the lifeline from service before performing any maintenance or inspection on the anchorage structure. Inspect the rope, termination, and thimble eye for wear, fraying, or deformation before each use and remove from service if any damage is found.

Technical Specifications

• Rope Diameter: 5/8 inch
• Length: 50 feet
• Termination Type: Sewn termination with steel thimble eye
• Connection Method: Shackle or carabiner
• Rope Color: Yellow
• Applicable Standards: OSHA 1926.502, OSHA 1910.140

Standard Information

• Brand: GUARDIAN FALL PROTECTION
• Manufacturer Part Number: 20075
