GSI PIPE & FITTINGS HT6GA26 Tapered HETO 06 inches

Product Description

The GSI PIPE & FITTINGS HT6GA26 is a duct fitting designed for effective airflow and space efficiency. This product is ideal for applications where a tapered take-off without a damper is required. It meets SMACNA Class 3 Leakage Standards, ensuring reliable performance. The fitting is equipped with a pre-sealed gasket made from EPDM rubber and a proprietary co-polymer, which guarantees zero VOC emissions.

• Engineered to meet SMACNA Class 3 Leakage Standards
• Pre-sealed gasket for enhanced sealing
• Composed of materials that ensure zero VOCs

Product Highlights

Product Information

Standard Information

• Brand: GSI PIPE & FITTINGS
• MPN: HT6GA26

Technical Specifications

• Material: Galvanized Steel (ASTM A653 and A924)
• Coating: G-60 Galvanized (ASTM A653 and ASTM A90)
• Pressure Rating: Designed per SMACNA Third Edition 2005 Section 4.8 Figure 4-6 Branch Connections
• Dimensional Tolerance: ± one quarter inches
