GSI PIPE & FITTINGS HT10GA26 Tapered HETO 10 inch

Product Description

The GSI PIPE & FITTINGS HT10GA26 tapered HETO is a duct fitting that is efficient for specific space needs and airflow management. Constructed with galvanized steel, it is suitable when a tapered take-off without a damper is required. This fitting includes a pre-sealed EPDM rubber gasket and a proprietary co-polymer for enhanced sealing.

• Constructed from durable galvanized steel
• Pre-sealed with EPDM rubber gasket
• Complies with SMACNA Class 3 Leakage Standards

Product Highlights

This fitting exceeds SMACNA Class 3 Leakage Standards and has zero VOC emissions, making it a reliable and environmentally friendly choice.

Product Information

Standard Information

• Material: Galvanized Steel (ASTM A653 and A924)
• Coating: G-60 Galvanized Coating (ASTM A653 and ASTM A90)

Technical Specifications

• Pressure Rating: Designed per SMACNA Third Edition 2005 Section 4.8 Figure 4-6 Branch Connections
• Dimensional Tolerance: ±1/4 inch
