GRUVLOK 0390080414 Reducer 2-1/2 x 2 Inch

Product Description

The GRUVLOK 0390080414 is a reducer fitting for grooved pipe connections. This fitting is made from ductile iron and malleable iron. It connects a two and a half inch grooved pipe to a two inch grooved pipe. Use this reducer in fire protection, HVAC, and industrial piping.

• Constructed from ductile iron and malleable iron
• Features grooved end connections
• Maximum pressure rating of five hundred PSI

Product Highlights

The GRUVLOK 0390080414 reducer is efficient for transitions between different pipe sizes in various applications.

Product Information

Standard Information

• Brand: GRUVLOK
• Model: 7010

Technical Specifications

• Material: 65-45-12 Ductile Iron, 32510 Malleable Iron
• Finish: Orange Painted
• Size A: 2-1/2 inches
• Size B: 2 inches
• Temperature Rating: -40 to 230 degrees F
• Pressure Rating: Maximum 500 PSI
• End Connection: 2-1/2 inch grooved x 2 inch grooved
• Gasket Details: Style C Grade E ASTM D2000 Green EPDM
• Approximate Weight: 3.5 lbs
