Gruvlok 0390079226 Grade T gasket (5 in)

Product Description

The Gruvlok 0390079226 Grade T gasket is a 5 in nominal nitrile gasket designed for Gruvlok FIG 7000-4 and 7400-01 couplings. The pressure-responsive gasket has inclined lips that compress on the pipe outside diameter to form a leak-tight seal that is further energized by internal line pressure and reinforced by coupling housings. It is rated -20 to 180 deg F and intended for petroleum, mineral and vegetable oil service and contaminated air.

• Material: Grade T nitrile rubber; temperature rating -20 to 180 deg F (-29 to 82 deg C).
• Designed for use with Gruvlok FIG 7000-4 and 7400-01 lightweight flexible couplings; nominal size 5 in.
• Pressure-responsive inclined gasket lips provide a leak-tight seal; sealing reinforced by coupling housings and internal line pressure.

Product Highlights

Grade T nitrile gasket, 5 in nominal, -20 to 180 deg F, for petroleum, vegetable and mineral oil applications; compatible with Gruvlok FIG 7000-4/7400-01; FM and UL listed.

Product Information

Standard Information

• Brand: GRUVLOK
• Manufacturer Part Number: 0390079226
• Country of Origin: US

Technical Specifications

• Brand: Gruvlok
• Manufacturer Part Number: 0390079226
• Manufacturer: ASC Engineered Solutions / Anvil International
• Product Type: Grade T gasket
• Material: Nitrile rubber
• Nominal Size: 5 in
• Compatible Couplings: Gruvlok FIG 7000-4; Gruvlok 7400-01
• Temperature Rating: -20 to 180 deg F (-29 to 82 deg C)
• Application: Petroleum products, vegetable oils, mineral oils, and air contaminated with petroleum oils
• Service Limitation: Not for use in hot water services
• Weight: 0.1 lbs
• Country of Origin: US
• Standards and Approvals: ASTM D2000; FM Approved; VdS/LPC Approved; UL/ULC Listed
• Type: T-only gasket
