Gruvlok 0390029817 16 x 12 in. Grooved End Concentric Reducer

Product Description

The Gruvlok 0390029817 is a concentric reducer for connecting pipes of varying sizes in a piping system. This fitting connects a sixteen-inch pipe to a twelve-inch pipe, both with grooved ends. It is made of ductile iron and features an orange rust-inhibiting paint. This reducer is designed for applications including air, natural gas, non-potable water, oil, and steam.

• Connects sixteen-inch and twelve-inch grooved pipes.
• Manufactured from ductile iron.
• Designed as a concentric reducer coupling.

Product Highlights

This product is ideal for use in industrial and commercial settings where different sizes of pipes must be joined effectively.

Product Information

Standard Information

• Manufacturer: Gruvlok
• MPN: 0390029817

Technical Specifications

• Item: Concentric Reducer
• Application: Air, Natural Gas, Non-Potable Water, Oil, Steam
• Class: Class 150
• Color: Orange
• Finish/Coating: Painted
• Fitting Side A Nominal Pipe Size: 16 inches
• Fitting Side A Outside Diameter: 16 inches
• Fitting Side A Type: Grooved
• Fitting Side B Nominal Pipe Size: 12 inches
• Fitting Side B Outside Diameter: 12 3/4 inches
• For Pipe Schedule: 40
• Material Grade: Grade B
• Overall Length: 14 inches
• Pipe Fitting Material: Ductile Iron
• Maximum Operating Pressure: 300 psi at 150°F
• Standards: ASTM A536
• Regulatory: NSF-61 and Low Lead Approved; cULus Listed; FM Approved; IAPMO UPC; LPCB; VdS; ASTM A53 Grade B
