GRUVLOK 0390024768 Fig 7069 4 in. Ductile Iron Grooved Lateral

Product Description

The GRUVLOK 390024768 is a lateral fitting made from ductile iron. It connects with Schedule 40 pipe and features a nominal size of four inches. The outside diameter measures four and a half inches. This fitting comes with a 45-degree angle and a Grade B Class 150 rating. The product has a rust-inhibiting finish and is colored orange. It supports a maximum operating pressure of three hundred psi at one hundred fifty degrees Fahrenheit and has a pressure rating of seven hundred fifty psi.

• Constructed from durable ductile iron.
• Designed for grooved connections to four-inch Schedule 40 pipe.
• Ideal for systems needing a 45-degree lateral connection.

Product Highlights

This fitting is part of the FIG 7069 series and is manufactured in the United States, ensuring quality and reliability.

Product Information

Standard Information

• Material: Ductile Iron
• Color: Orange

Technical Specifications

• Size: 4 inches
• Type: Lateral
• Angle: 45 Degrees
• Class: Grade B Class 150
• Application: For Pipe Schedule 40
• Maximum Operating Pressure: 300 psi at 150 Degrees F
• Dimensions: 4-1/2 in OD
• Domestic/Import: Domestic
• End Style: Grooved
• Finish: Rust Inhibiting Painted
• Pressure Rating: 750 psi
• Series: FIG 7069
