Gruvlok 0386014120 FIG 7042 Branch Outlet Coupling, 3 x 1 in

Product Description

The Gruvlok® FIG 7042 Branch Outlet Coupling, MPN 0386014120, connects two sections of grooved end pipe and forms a reducing outlet connection. This coupling is suitable for various applications and is made from durable materials to ensure longevity.

• Designed for use with grooved end pipe
• Compatible with water service, diluted acids, and many chemical solutions
• Pressure rated up to 500 psi

Product Highlights

This coupling features a robust design and reliable sealing performance thanks to its Grade E EPDM gasket and ductile iron clamp. It's painted with rust-inhibiting finish for increased durability.

Product Information

Standard Information

• Manufacturer: Gruvlok®
• Part Number: 3113570

Technical Specifications

• Nominal Size: 3 x 1 in
• Connection Type: FNPT
• Pressure Rating: 500 psi
• Temperature Range: -40 to 150 degrees F
• Dimensions: 7-1/4 in W x 3-1/4 in D
• Clamp Material: Ductile Iron
• Gasket Material: Grade E EPDM
• Bolt Material: 304 Stainless Steel
• Includes: Zinc Electroplated Heavy Hex Nuts and Bolts
