Grundfos UPSE15-58F Upse 15-58f High Efficiency Ecm Wet Rotor Circulator Pump With Universal Programming 1/20 HP

Product Description

The GRUNDFOS UPSE15-58F is a high-efficiency circulator fitted with an electronically commutated motor (ECM). Designed to circulate liquids in heating and cooling systems, it offers a high Energy Rating based on the Hydraulic Institute Energy Rating. The pump features constant pressure, proportional pressure, and constant curve, each with three settings, making it suitable for almost any hydronic application.

• High-efficiency heating circulator built with an ECM for energy savings
• Dry-run protection feature stops the pump if water is not detected in the system
• Pumps are self-venting in any setting and mode to help avoid unwanted noise and reduced performance

Product Highlights

The UPSE15-58F features warning and alarm read-outs, a robust startup, and a smaller conduit box for easy installation.

Product Information

Standard Information

• Brand: GRUNDFOS
• Manufacturer Part Number: UPSE15-58F

Technical Specifications

• Application: Heating
• Material: Cast Iron
• Max Flow (GPM): 13.6
• Max Head (Ft): 19
• Voltage: 115V
• Horse Power: 1/20
• Max Pressure (PSI): 175
• Connection Type: Flanged x Flanged
• Amperage: 0.7
• Casing: Cast Iron
• Circulator Pump Type: high-efficiency w/ ECM motor and (3) modes - constant pressure, proportional pressure and constant speed
• Connections: Flanged (GF 15/26)
• Circulator Height (Flange to Flange): 6-1/2"
• Electrical Specs: 115V, 60 Hz, 38W max, 0.70 Amps max
• Head Range: 0-19 ft
• Flow Range: 0-13.6 GPM
• Operating Temperature Range: 36°F - 230°F
• Max Operating Pressure: 175 psi
• Sound Pressure Level: 25 dB (A)
• Hydraulic Institute Energy Rating (ER): 193
• Dimensions (Depth x Width x Height): 5.31" x 5.23" x 6.50"
• Weight (lbs): 5.9 lbs
• AMP: 0.71
• ASTM: ASTM A-48 25A
• Maximum Feet of Head: 19
• Maximum Temperature: 230
• Minimum Temperature: 36
• Product Type: Circulator Pump
• Pump Body Material: Cast Iron
• Pump Phase: 1
• Watts: 38
