Product Description
The Grundfos 96806136 is a high-quality uni-flange isolator valve set designed specifically for use with series UP circulator pumps. This standard-sized, metal valve set features a silver finish and ensures top performance under typical operating conditions.
- 1 inch copper connections for easy integration.
- Includes essential components: rotating flanges, lever handle ball valves, and dielectric sleeves.
- Max pressure tolerance of 150 PSI and temperature up to 230 degrees Fahrenheit.
Product Highlights
Constructed from durable, corrosion-resistant metal, the Grundfos 96806136 ensures longevity and reliability. Its dielectric capabilities prevent galvanic corrosion, and the full port shut-off ball valve feature allows for easy maintenance without system drainage. Moreover, the swivel flange design facilitates optimal pump positioning.
Product Information
Standard Information
-
Brand: Grundfos
-
MPN: 96806136
-
Material: Metal
-
Color: Silver
Technical Specifications
-
Connection Type: 1 inch copper
-
Pressure Rating: 150 PSI
-
Temperature Rating: Maximum 230 degrees Fahrenheit
-
Components Included: Rotating flanges, ball valves, dielectric sleeves, EPDM gaskets, bolts, nuts
