GRUNDFOS 59896343FRC UPS15-58FRC 3-Speed Circulator Pump 59896343FRC

Product Description

The GRUNDFOS UPS15-58FRC circulator pump is designed for heating and air-conditioning applications. It is suitable for use in central and district heating systems. This pump features a rotated flanged housing along with an integral check valve. The construction includes cast iron and a composite impeller, ensuring durability.

• Three-speed motor for power and noise adjustment
• Constructed with robust cast iron housing
• Operates in closed systems with a liquid temperature up to 230°F

Product Highlights

Efficient for hydronic heating and hot water recirculation, this circulator pump provides reliable operation.

Product Information

Standard Information

• Brand: GRUNDFOS
• MPN: 59896343FRC

Technical Specifications

• Application: Hydronic heating, Fan coil heating, Solar heating, Radiant heating systems, Hot Water Recirculation
• Material: Cast Iron
• Horse Power: 1/25 HP
• Input Voltage: 115 V
• Frequency: 60 Hz
• Phase: 1
• Max Flow: 17.2 US gpm
• Max Head: 19.5 ft
• Maximum Operating Pressure: 145 psi
• Liquid Temperature Range: 35.6 to 230 °F
• Ambient Temperature Range: 35.6 to 104 °F
• Connection Type: Flanged x Flanged
• Connection Size: 3/4
• Port-to-port Length: 6.54 in
• Weight: 6.28 lb
• Approvals: UL, CSA
• Number of Poles: 2
• Rated Flow: 8.5 US gpm
• Rated Head: 10.47 ft
• Power Input in Speed 1: 60 W
• Power Input in Speed 2: 80 W
• Max Power Input: 87 W
• Current in Speed 1: 0.55 A
• Current in Speed 2: 0.66 A
• Current in Speed 3: 0.75 A
