GREENLEE 33960 STI Fast Spiral Flute Tap

Product Description

The GREENLEE 33960 is a STI tap made for creating threads that accept helical coil wire screw thread inserts. This tool features fast spiral flutes which efficiently lift chips during the tapping process, which helps in blind hole applications. It is ideal for softer materials, minimizing issues with stringy chips.

• STI tap for helical coil wire inserts.
• Fast spiral flutes for effective chip removal.
• Recommended for softer materials to avoid chip issues.

Product Highlights

This tap is designed for efficiency and ease of use in various materials.

Product Information

Standard Information

• Manufacturer Part Number: 33960
• Brand Name: GREENLEE

Technical Specifications

• Thread Size: 7/16-14
• Thread Type: UNF
• Thread Length: 1-7/16 inches
• Overall Length: 3-5/32 inches
• Number of Flutes: 3
• Chamfer Type: Bottoming
• Cutting Direction: Right Hand
• Class of Fit: H3
• Tap Drill Size: 15/32 inches
• Material: HSS
• Finish: Bright
• Standard Approvals: ISO 9001:2008
• Package Quantity: 1/Each
• Flute Type: Spiral
