Greenlee 1795AV Chassis Punch 2-5/8 Inches

Product Description

The GREENLEE 1795AV is a chassis punch designed to cut clean, precise holes in electrical enclosures, panel boxes, and sheet metal chassis. Chassis punches like this one are standard tools for electricians and panel builders who need to create conduit knockouts or device openings without distorting the surrounding material. The 1795AV produces a 2-5/8 inch diameter hole and is driven by a draw stud and hydraulic or manual punch driver. It weighs 5.1 pounds, making it a solid, durable unit suited for regular shop and field use.

This punch is used in electrical and low-voltage installation work wherever a clean knockout is required in metal enclosures, junction boxes, or chassis panels. Typical applications include adding conduit entries to load centers, pulling wire through metal panels, and fabricating custom enclosures. It is most commonly used by licensed electricians, electrical contractors, and panel shop fabricators working on both commercial and residential projects.

Key Features

• Produces a 2-5/8 inch diameter hole in sheet metal chassis and enclosures
• Compatible with standard draw stud punch driver systems
• Solid construction at 5.1 pounds for durability under repeated use
• Designed for clean cutouts with minimal burring on the workpiece

Compatibility

Designed as an OEM-style replacement or supplemental chassis punch for use with standard Greenlee draw stud and hydraulic punch driver systems. No specific model compatibility data was provided in the product input.

Installation Notes

Installation of chassis punches is typically performed by licensed electricians or panel fabricators. Always de-energize and lock out the enclosure before beginning any knockout work on live panels. Use appropriate draw studs and a punch driver rated for the die size, and follow NEC guidelines for conduit entry spacing and enclosure integrity. Inspect the die and punch for wear or cracks before each use.

Technical Specifications

• Hole Diameter: 2-5/8 inches
• Weight: 5.1 pounds
• UPC: 78331004252

Standard Information

• Brand: GREENLEE
• Manufacturer Part Number: 1795AV
