Product Description
The Gree CAS18HP230V1BC is an 18,000 BTU B Style Cassette Indoor Unit designed for heating and cooling applications. This heat pump unit operates on 208-230 VAC, single phase, 60 Hz power, utilizing R-410A refrigerant. It provides multi-directional airflow for even temperature distribution in rooms up to 800 sq ft. The unit features a low-profile, flush-mounted ceiling cassette design, suitable for residential and light commercial environments.
- Includes a remote control for temperature and settings adjustment.
- Provides both heating and cooling capabilities with an 18,000 BTU capacity.
- Features a low-profile, flush-mounted ceiling cassette design for discreet installation.
Product Highlights
Quiet operation with multi-directional airflow for even temperature distribution, compatible with multi-zone outdoor condensers.
Product Information
Standard Information
-
Brand: GREE
-
Manufacturer Part Number: CAS18HP230V1BC
-
Country of Origin: China
Technical Specifications
-
AHRI Usage: Indoor AHU
-
Blower Motor Type: PSC (Permanent Split Capacitor)
-
CFM: 265-418
-
Cooling Capacity: 18000 BTU/h
-
Frequency: 60 Hz
-
EER: 10.25
-
Energy Star Rated: Yes
-
Equipment Type: Heat Pump
-
ETL Listed: No
-
Heating Capacity: 18000 BTU/h
-
Liquid Line Fitting Type: Flare
-
Liquid Line Size: 1/4"
-
Mounting Type: Ceiling Cassette
-
Phase: Single
-
Product Family: Vireo Gen3
-
Refrigerant Type: R-410A
-
Remote Control Included: Yes
-
SEER Rating: 20
-
Sound Level (dBA): 35-47
-
Suction Line Fitting Type: Flare
-
Suction Line Size: 1/2"
-
UL Listed: No
-
Input Voltage: 208-230 VAC
-
Multi Zone: No
-
Replaces MPN: CAS18HP230V1AC
-
Drain Size: 1-1/4"
-
Tonnage: 1.5 Ton
-
Unit Type: Indoor Unit
-
Compatibility: Current Multi & 3Vir Models
-
Installation Location: Indoor
-
AHRI Certified: Yes
-
Product Type: Mini-Split
-
Fan Speed: 4 Speed
-
Use: Heating and A/C
