GREAVES G53 Ground Lock Adapter

Product Description

The GREAVES G53 Ground Lock Adapter is designed for electrical grounding applications. It is part of the Ground-Lok pipe clamp system. The adapter features a cast bronze body and a plated steel screw, ensuring dependable connections. This adapter is compatible with one half inch rigid conduit and bronze water pipes, suitable for eight to four aught AWG stranded conductors.

• Constructed from durable cast bronze and plated steel for strength.
• Compatible with one half inch rigid conduit and bronze pipes, supporting various conductor sizes.
• Approved by UL and CSA, meeting electrical safety standards.

Product Highlights

The G53 adapter includes an interchangeable clamp-adapter mechanism with interlocking teeth for secure installation in multiple directions. It also comes with a G50 wire adapter for added convenience.

Product Information

Standard Information

• Material: Cast Bronze (Body), Plated Steel (Screw)
• Used On: 1/2 Inch Rigid Conduit, Bronze Water Pipe

Technical Specifications

• Conductor Size: 8 to 4/0 AWG Stranded
• Installation: (2) Screw Connector to Pipe, (4) Screw Clamp
• Approvals: UL, CSA (Canada and US)
• IPS Size: 1/2 to 1 Inch
• Brand (System): Ground-LOK
• Includes: G50 Wire Adapter With Lay-In Capability
