Graco D54311 Husky 716 Metallic Bolted Pump 3/4 in NPT Ports

Product Description

The Graco D54311 Husky 716 pump features a stainless steel fluid section and center. It is designed for reliable performance in various pumping applications.

• Maximum flow rate of 16.0 gallons per minute
• 1/4 NPT air inlet for efficient air supply
• Wet and dry suction lift capabilities of 25.00 feet and 15.00 feet, respectively

Product Highlights

This pump is suitable for heavy-duty applications requiring robustness and efficiency.

Product Information

Standard Information

• Brand: Graco
• MPN: D54311
• Country Of Origin: United States

Technical Specifications

• Air Inlet: 1/4 NPT
• Air Exhaust: 3/8 NPT
• Maximum Pressure: 100 psi
• Max Solids: 3/32 in Diameter
• Ball Material: PTFE
• Wetted Materials: Stainless Steel
• Diaphragm Material: PTFE
• Check Seat Material: Stainless Steel
• Inlet/Outlet Port Type: NPT
• Inlet/Outlet Port Sizes: 3/4 in
• Suction Lift: Wet - 25.00 ft, Dry - 15.00 ft
• Supporting Product Brochure: http://www.graco.com/us/en/products/process/husky-716-double-diaphragm-pump.html
