Graco 204254 Fire-Ball 300 Series 5:1 Air-Operated Oil Piston Pump

Product Description

The Graco 204254 Fire-Ball 300 Series is an air-operated oil piston pump designed for continuous-duty fluid transfer. This pump is ideal for automotive dealerships, service shops, and in-plant operations.

• Max working pressure of 1500 psi
• Operating temperature range of four degrees Fahrenheit to 158 degrees Fahrenheit
• 1/2 inch inlet port

Product Highlights

This pump features a thick cast aluminum air motor housing for increased durability and a non-corrosive design for long life. Its double-acting pump mechanism ensures smooth fluid flow.

Product Information

Standard Information

• Brand: Graco
• MPN: 204254

Technical Specifications

• Air Motor Diameter: 3 inches
• Maximum Operating Pressure: 180 psi
• Pump Type: Bare Pump
• Fluid Outlet: 1/2 inch NPT(f)
• Fluid Inlet: 1 1/2 inch NPT(f)
• Container Volume: 55 gallons
• Flow Rate: 3.00 gallons/minute
• Fluid Medium: Motor oil, synthetic oil, hydraulic oil, gear oil, automatic transmission fluid
• Weight: 29 pounds
• EAN/UPC: 633955520783
