Goulds Pumps Inc 5CS05422C 4 CS Series Submersible Well Pump

Product Description

The Goulds Pumps Inc 5CS05422C is a reliable submersible well pump made for effective water systems. It uses a half horsepower motor and operates on 230 volts. This pump is built from stainless steel, ensuring it resists corrosion and maintains durability. It fits into water wells four inches in diameter or larger and works efficiently with its twelve-stage design.

• Stainless steel for durability and resistance.
• Responsive with a 1/2 HP motor at 230 volts.
• Designed for installation in 4-inch or larger wells.

Product Highlights

This well pump provides a consistent flow rate, making it suitable for various water systems, and includes cast-in safety line loops to simplify the installation process.

Product Information

Standard Information

• Brand: Goulds
• Manufacturer: Xylem

Technical Specifications

• MPN: 5CS05422C
• Series: GS
• Product Type: Submersible well pump
• Application: Water systems
• Horsepower: 1/2 HP
• Voltage: 230 Volts
• Phase: 1
• Frequency: 60 Hz
• Speed: 3450 rpm
• Stages: 12
• Motor Type: 2-wire PSC
• Minimum Well Size: 4 inches
• Rotation: Counterclockwise
• Discharge Connection: 1-1/4 NPT
• Flow Rate: 5 GPM
• Best Efficiency Flow: 5 gpm
• Flow Range: 1.2 - 7.5 gpm
• Pump Casing: AISI 304 stainless steel
• Impeller Material: Noryl
• Check Valve Poppet: AISI 304 stainless steel
• Bearing: Proprietary engineered polymer
• Motor Adapter: AISI 303 stainless steel
• Cable Guard: AISI 304 stainless steel
• Suction Screen: AISI 304 stainless steel
• Thermal Protection: Yes
• Control Box: Not required
• Amps: 4
• Material: Stainless Steel
• Diameter: 4 inches
• Wire Count: 2 Wire
