Goodman VSZ140181 1.5 Ton 14 Seer Single Phase GMC Series Heat Pump Condenser R410A

Product Description

The GOODMAN VSZ140181 is a 1.5 Ton 14 SEER single-phase GMC series heat pump condenser designed for use with R410A refrigerant. It features a high-efficiency compressor and a copper tube/aluminum fin coil. This unit is equipped with factory-installed components including a bi-flow liquid line filter, suction line accumulator, crankcase heater, and high-capacity muffler.

• High-efficiency compressor
• Copper tube/aluminum fin coil
• Factory-installed bi-flow liquid line filter
• High and low-pressure switches
• Contactor with lug connections

Product Highlights

This heat pump condenser is designed for efficiency and includes multiple factory-installed components for ease of installation and reliable operation.

Product Information

Standard Information

• Brand: GOODMAN
• Manufacturer Part Number: VSZ140181

Technical Specifications

• BtuH Cooling: 24,000
• BtuH Heating Input: 24000
• COP: 4.6
• Depth: 29"
• EER: 11.5
• HSPF: 8.2
• Height: 38-1/4"
• Liquid Conn.: 3/8"
• Max. Fuse Size: 20
• Min. Circuit Amps: 12.2
• Motor Type: PSC
• Nom. Tons: 1-1/2
• Phase: Single
• Refrigerant: R410A
• SEER: 14
• Suction Fitting: 3/4"
• Volts: 208/230
• Width: 29"
