GOODMAN RXB12AXVJU 12,000 BTU Outdoor Condenser

Product Description

The GOODMAN RXB12AXVJU is a robust outdoor condenser specifically made for single-zone installations. This unit operates in both heating and cooling modes, utilizing R-410A refrigerant for effective temperature control. It features an inverter variable speed compressor, ensuring efficient operation across a range of conditions.

• Cools and heats using R-410A refrigerant.
• Designed for outdoor single-zone installation.
• Includes auto restart and self-diagnosis with display.

Product Highlights

Great for residential applications, the unit provides reliable comfort in varied climates and has advanced features that enhance usability.

Product Information

Standard Information

• Type: Outdoor Condenser
• Product Line: 17-Series

Technical Specifications

• Operating Mode: Heating and Cooling
• Cooling BTU: 12000
• Maximum Number of Zones: 1
• Multi-Zone Compatible: No
• Refrigerant Type: R-410A
• Installation Location: Outdoor
• Minimum Sound Level: 48 dB
• Low Ambient Heating: Yes
• Minimum Outdoor Temperature for Heating: 5 F
• Minimum Outdoor Temperature for Cooling: 50 F
• Maximum Line Length: 65.625 Feet
• Gas Connection Size: 3/8 Inch
• Liquid Connection Size: 1/4 Inch
• Condensate Drain Size: 3/4 Inch
• Product Height: 21 5/8 Inches
• Product Width: 25 15/16 Inches
• Product Depth: 10 3/4 Inches
• Product Weight: 57 Pounds
• AHRI Certified: Yes
• Input Voltage: 208/230 Volts
• Phase: 1
• Frequency: 60 Hz
• Recommended Breaker Size: 15 Amps
• Parts Warranty: 5 Years
