Goodman GMH80403AN 80% afue 40,000 btu 2 Stage Upflow/Horizontal Gas Furnace

Product Description

The Goodman GMH80403AN is an 80% AFUE, 40,000 BTU, two-stage upflow/horizontal gas furnace. Goodman's Dual Saver technology operates at a low heating stage most of the time, eliminating temperature swings. The furnace features a dual-diameter tubular heat exchanger made with aluminized steel for efficient heat transfer and longevity. It is protected by a durable steel cabinet with foil insulation.

• Equipped with Dual$aver Technology for efficient operation.
• Features a dual-diameter tubular heat exchanger.
• Protected by a durable steel cabinet with foil insulation.

Product Highlights

This Goodman gas furnace provides efficient and consistent heating with its two-stage operation and durable design.

Product Information

Standard Information

• Brand: GOODMAN
• Manufacturer Part Number: GMH80403AN

Technical Specifications

• Type: Gas Furnace
• Product Line: GMH8
• Fuel Type: Natural Gas
• Vent Type: Chimney Vent
• Modulating/Staging: Two Stage
• Blower Motor Type: PSC Multi-Speed
• Configuration: Upflow/Horizontal
• Gas Conversion Kit: Available
• DOE Regional Compliance: Nationwide (Except CA)
• AFUE: 80 %
• Heating BTU: 40000
• High Fire Input: 40000 BTU
• High Fire Output: 32000 BTU
• Low Fire Input: 30000 BTU
• Low Fire Output: 24000 BTU
• Maximum Air Flow: 1200 CFM
• Low NOx Emissions: No
• Phase: 1
• Frequency: 60 Hz
• Minimum Circuit Ampacity: 8.1 Amps
• Recommended Breaker Size: 15 Amps
• Flue Connection Size: 4 Inches
• Cabinet Width: 14 Inches
• Product Height: 33 3/8 Inches
• Product Width: 14 Inches
• Product Depth: 28 3/4 Inches
• ETL Listed: Yes
• AHRI Certified: Yes
• ISO Certified: Yes
• AHRI Reference Number: 5012553
