Goodman ftxq09asbu9 Wall Mount Indoor Unit 9000 Btu 115V

Product Description

The GOODMAN ftxq09asbu9 is a 9,000 BTU/h wall-mounted indoor unit designed for ductless mini-split systems operating on 115-volt single-phase power. It uses R-32 refrigerant, which carries a lower global warming potential than R-410A. Inverter-driven technology allows the compressor to modulate speed continuously, reducing energy consumption and maintaining consistent room temperature without the temperature swings typical of single-speed systems. The unit includes an auto-swing louver assembly for broad airflow distribution and a Hot Start function that delays fan operation until the heat exchanger reaches an appropriate discharge temperature. HVAC technicians install and commission this unit as the indoor half of a matched mini-split system.

The ftxq09asbu9 is suited for residential and light-commercial single-zone applications where a wall-mounted air handler is preferred. Typical installations include bedrooms, additions, server rooms, and other spaces where independent zone control is needed. The compact cabinet profile and low-profile mounting bracket make it adaptable to rooms with limited wall clearance. It is intended for use as part of a complete ductless system paired with a compatible outdoor condensing unit.

Key Features

• 9,000 BTU/h capacity for single-zone heating and cooling
• 115-volt operation for compatibility with standard residential circuits
• R-32 refrigerant with lower global warming potential than R-410A
• Inverter compressor technology for variable-speed, energy-efficient operation
• Auto-swing wide-angle louvers for even airflow distribution
• Hot Start function prevents cold air discharge during heating mode startup

Compatibility

Designed as an OEM-style indoor wall-mounted air handler for use with a compatible R-32 ductless mini-split outdoor condensing unit rated for 9,000 BTU/h at 115 volts.

Installation Notes

Installation of this unit should be performed by a licensed HVAC technician holding an EPA Section 608 certification, as R-32 is a mildly flammable (A2L) refrigerant requiring specific handling procedures and listed tools. Power to the circuit must be disconnected and locked out before mounting, wiring, or making refrigerant connections. The indoor unit mounting surface must be capable of supporting the unit weight, and the refrigerant line set, condensate drain, and low-voltage control wiring must be routed per the manufacturer installation manual and applicable local mechanical codes.

Technical Specifications

• Cooling Capacity: 9,000 BTU/h
• Voltage: 115 volts
• Refrigerant: R-32
• Unit Type: Wall-mounted indoor air handler
• System Type: Ductless mini-split

Standard Information

• Brand: GOODMAN
• Manufacturer Part Number: ftxq09asbu9
