Goodman dh6te09040 Heat Pump Condenser 92000 Btu/h 460V

Product Description

The GOODMAN dh6te09040 is a commercial-grade outdoor heat pump condenser rated at 92,000 BTU/h cooling and 85,000 BTU/h heating. It operates on 460 volts, triple phase power and uses R-32 refrigerant, which is A2L compatible. The unit delivers an EER2 of 11.4 and an IEER of 16.0, making it well suited for high-efficiency commercial applications. A scroll-type tandem compressor and top-discharge configuration are standard. Liquid line OD is 5/8 inches and suction line OD is 1-1/8 inches. Licensed commercial HVAC technicians are the primary installers for this class of equipment.

This condenser is designed for commercial split-system heat pump installations in the 7.5-ton range. It is part of the DH6TE_4 Series and is intended for outdoor placement in three-phase electrical environments. Typical applications include light commercial buildings, retail spaces, and similar facilities requiring reliable year-round heating and cooling. The two-stage operation supports better capacity control across varying load conditions. Field pairing with a compatible air handler is required to complete the split system.

Key Features

• R-32 refrigerant with A2L compatibility for current and emerging code requirements
• 92,000 BTU/h maximum cooling capacity and 85,000 BTU/h maximum heating capacity
• EER2 of 11.4 and IEER of 16.0 for strong part-load efficiency
• 460V triple-phase power with scroll compressor and two-stage operation
• Top-discharge, single-speed blower configuration for standard rooftop or ground-mount installs
• Compact footprint: 35.5 inches wide by 35.5 inches deep by 41.5 inches tall

Compatibility

Designed for use in commercial three-phase split-system heat pump configurations in the 7.5-ton capacity class. Compatible systems require a matched indoor air handler rated for R-32 refrigerant and 460V triple-phase operation. Consult the DH6TE_4 Series product documentation for approved indoor unit pairings.

Installation Notes

Installation must be performed by a licensed HVAC technician holding applicable EPA Section 608 certification for A2L refrigerants. Shut off and lock out all electrical power at the disconnect before making any electrical or refrigerant connections. Follow all local mechanical and electrical codes, including NEC requirements for three-phase equipment and any adopted A2L refrigerant handling standards. Do not operate the unit without verifying that the matched indoor coil and line set are correctly sized and leak-tested per manufacturer guidelines.

Technical Specifications

• BTU Cooling Rating: 92,000 BTU/h
• BTU Heating Rating: 85,000 BTU/h
• EER2: 11.4
• IEER: 16.0
• HSPF: 3.5
• Voltage: 460V
• Phase: Triple Phase
• Amperage: 6.4 / 20 / 17.9 amps
• Stages: Two
• Refrigerant Type: R-32
• A2L Compatible: Yes
• Compressor Type: Scroll
• Configuration: Top Discharge
• Blower Type: 1 Speed
• Liquid Line OD: 5/8 inches
• Suction Line OD: 1-1/8 inches
• Width: 35.5 inches
• Depth: 35.5 inches
• Height: 41.5 inches
• Weight: 386 pounds
• Application: Commercial
• Indoor/Outdoor: Outdoor
• Energy Star Compliant: No
• Style Name: DH6TE_4 Series

Standard Information

• Brand: GOODMAN
• Manufacturer Part Number: dh6te09040
