Goodman dc6te12030 Air Conditioner 10 Ton 208/230V R-32

Product Description

The GOODMAN dc6te12030 is a 10-ton commercial packaged air conditioner designed for demanding cooling applications requiring high efficiency and reliable output. Rated at 118,000 BTU/h maximum cooling capacity, this unit operates on 208/230 volts, 60 Hz, 3-phase power and uses R-32 refrigerant, a lower-GWP alternative gaining wide adoption in commercial HVAC systems. A tandem compressor configuration supports consistent performance across varying load conditions. The unit carries an EER2 rating of 11.4 and an IEER rating of 16.4, meeting efficiency benchmarks relevant to commercial building compliance and energy cost management. Sweat connections are used for both liquid and suction lines. Licensed commercial HVAC technicians are the primary installers for this equipment.

This unit is suited for commercial cooling installations where 3-phase power is available and a 10-ton capacity matches the building load calculation. The sweat connection type requires brazing of refrigerant lines on-site. The 5/8-inch liquid line and 1-1/8-inch suction line sizes should be factored into line set planning and material procurement before installation. Typical applications include light commercial buildings, retail spaces, and multi-zone commercial environments requiring a high-capacity condensing solution with R-32 refrigerant compatibility.

Key Features

• 10-ton nominal cooling capacity with 118,000 BTU/h maximum output
• R-32 refrigerant — lower global warming potential compared to R-410A
• 11.4 EER2 and 16.4 IEER efficiency ratings for commercial compliance
• Tandem compressor design for sustained performance under variable load
• 208/230V, 60 Hz, 3-phase electrical configuration for commercial power infrastructure
• Sweat connection type with 5/8-inch liquid line and 1-1/8-inch suction line

Compatibility

Designed for commercial HVAC systems requiring a 10-ton, 3-phase air conditioning unit with R-32 refrigerant and sweat-type refrigerant line connections. Verify that existing or planned air handlers, coils, and line sets are rated and sized for R-32 before installation.

Installation Notes

Installation must be performed by a licensed HVAC technician holding an EPA Section 608 certification, as R-32 is an A2L mildly flammable refrigerant requiring specific handling precautions and compatible recovery equipment. Disconnect and lock out all electrical power before servicing. The 60-amp fuse requirement must be matched by properly sized overcurrent protection per NEC guidelines. Confirm that the installation site, line set routing, and air handler are all rated for R-32 refrigerant prior to commissioning.

Technical Specifications

• Nominal Capacity: 10 ton
• Maximum Cooling Capacity: 118,000 BTU/h
• EER2 Rating: 11.4
• IEER Rating: 16.4
• Voltage Rating: 208/230 volts, 60 Hz, 3-phase
• Fuse Size: 60 amps
• Refrigerant Type: R-32
• Connection Type: Sweat
• Liquid Line Size: 5/8 inches
• Suction Line Size: 1-1/8 inches
• Dimensions: 35.5 inches W x 35.5 inches D x 41.75 inches H

Standard Information

• Brand: GOODMAN
• Manufacturer Part Number: dc6te12030
