Goodman dc6te09030 Air Conditioner 7.5 Ton 208/230V R-32

Product Description

The GOODMAN dc6te09030 is a 7.5-ton commercial split-system air conditioner designed for demanding light-commercial cooling applications. Running on 208/230V, 60 Hz, 3-phase power, it uses R-32 refrigerant and features a tandem compressor configuration that supports up to 95,000 BTU/h of maximum cooling output. With an EER2 rating of 12.3 and an IEER rating of 16.4, this unit delivers strong part-load efficiency that matters in variable-demand commercial environments. Sweat-type refrigerant connections keep field fabrication straightforward for certified technicians working with R-32 systems.

This unit is suited for light-commercial and larger residential applications where 3-phase power is available and cooling loads exceed the range of standard residential equipment. Typical installations include retail spaces, small office buildings, and multi-unit facilities requiring a single high-capacity condensing unit. The tandem compressor design supports capacity staging, which improves efficiency and system longevity under variable load conditions. A licensed HVAC technician with EPA 608 certification is required for handling R-32 refrigerant during installation and commissioning.

Key Features

• 7.5-ton nominal cooling capacity with up to 95,000 BTU/h maximum output
• R-32 refrigerant — lower global warming potential compared to R-410A
• Tandem compressor configuration supports capacity staging and improved part-load efficiency
• IEER rating of 16.4 and EER2 rating of 12.3 for strong seasonal efficiency
• 208/230V, 60 Hz, 3-phase power input suits light-commercial electrical service
• Sweat connection type with 5/8-inch liquid line and 1-1/8-inch suction line

Compatibility

Designed as an OEM-style light-commercial condensing unit for 3-phase R-32 split-system installations requiring 7.5-ton capacity.

Installation Notes

Installation must be performed by a licensed HVAC contractor holding EPA 608 certification, as R-32 is an A2L mildly flammable refrigerant subject to specific handling and safety requirements. Disconnect and lock out all electrical power at the disconnect box before making any electrical or refrigerant connections. Verify that the field-supplied line set matches the specified sweat connection sizes and that the installation site meets local mechanical and electrical code requirements for 3-phase equipment. Consult the manufacturer installation manual and applicable local codes before proceeding.

Technical Specifications

• Nominal Capacity: 7.5 ton
• Maximum Cooling Output: 95,000 BTU/h
• EER2 Rating: 12.3
• IEER Rating: 16.4
• Voltage Rating: 208/230V, 60 Hz, 3-Phase
• Fuse Size: 50 amps
• Refrigerant Type: R-32
• Connection Type: Sweat
• Liquid Line Size: 5/8 inches
• Suction Line Size: 1-1/8 inches
• Dimensions: 35.5 inches W x 35.5 inches D x 41.75 inches H

Standard Information

• Brand: GOODMAN
• Manufacturer Part Number: dc6te09030
