Goodman dc3sea6030 Air Conditioner 5 Ton 208/230V 3-phase

Product Description

The GOODMAN dc3sea6030 is a 5-ton commercial-grade split-system air conditioner designed for three-phase electrical service at 208/230 volts, 60 Hz. It uses R-32 refrigerant and a scroll compressor to deliver up to 56,500 BTU/h of cooling capacity. With a SEER2 rating of 13.4 and EER2 ratings up to 11.5, this unit meets modern efficiency benchmarks for light commercial and larger residential applications. Licensed HVAC technicians handle installation, which involves refrigerant handling certification due to the R-32 charge. The cabinet measures 35.5 inches wide by 35.5 inches deep by 39.5 inches tall, making site clearance planning straightforward.

This unit fits light commercial and large residential cooling applications where three-phase power is available. The 208/230V three-phase configuration makes it appropriate for small commercial buildings, multi-family properties, and industrial facilities with existing three-phase electrical infrastructure. Sweat copper connections on both the 3/8-inch liquid line and 7/8-inch suction line allow for standard brazing techniques during field installation. The scroll compressor design provides reliable, low-vibration operation suited to applications that demand consistent cooling output across extended run cycles.

Key Features

• 5-ton nominal cooling capacity with up to 56,500 BTU/h output
• 208/230V, 60 Hz, 3-phase power supply for commercial electrical systems
• R-32 refrigerant with lower global warming potential compared to R-410A
• Scroll compressor for efficient, low-vibration operation
• Sweat connection type on 3/8-inch liquid line and 7/8-inch suction line
• SEER2 rating of 13.4 meeting current efficiency standards

Compatibility

Designed as an OEM-style replacement or new-installation outdoor condensing unit for three-phase split-system air conditioning applications requiring 5-ton capacity and R-32 refrigerant.

Installation Notes

Installation must be performed by an EPA Section 608 certified HVAC technician due to the R-32 refrigerant charge. Disconnect and lock out all electrical power before servicing or connecting refrigerant lines. Brazing sweat connections requires a nitrogen purge to prevent internal oxidation. Verify that the electrical service panel and disconnect sizing meet the 35-amp fuse requirement and comply with applicable NEC guidelines.

Technical Specifications

• Nominal Capacity: 5 ton
• Max Cooling Capacity: 56,500 BTU/h
• SEER2 Rating: 13.4
• EER2 Rating: Up to 11.5
• Voltage Rating: 208/230 V, 60 Hz, 3 Phase
• Fuse Size: 35 A
• Refrigerant Type: R-32
• Compressor Type: Scroll
• Connection Type: Sweat
• Liquid Line Size: 3/8 inches
• Suction Line Size: 7/8 inches
• Sound Level: 72 dBA
• Dimensions: 35.5 inches W x 35.5 inches D x 39.5 inches H

Standard Information

• Brand: GOODMAN
• Manufacturer Part Number: dc3sea6030
