GOODMAN CHPEA6030C3 5-Ton Cased A Coil

Product Description

The Goodman CHPEA6030C3 is a five-ton cased A coil suitable for both upflow and downflow applications. This evaporator coil is designed for use with R-32 refrigerant and features a robust all-aluminum construction. It comes with a factory-installed thermal expansion valve for enhanced performance.

• All-aluminum evaporator coil
• Versatile for upflow and downflow configurations
• Includes factory-installed thermal expansion valve

Product Highlights

This coil's casing features insulation to minimize condensation and is complemented by a thermoplastic drain pan with secondary drainage options.

Product Information

Standard Information

• Brand: GOODMAN
• MPN: CHPEA6030C3

Technical Specifications

• Product Type: Evaporator Coil
• Product Line: CAPTA
• Unit Type: Indoor
• Coil Type: A Coil
• Tonnage: 5.0 Ton
• Cooling Capacity: 60000 BTU
• Refrigerant Type: R-32
• Airflow Direction: Vertical
• Configuration: Upflow/Downflow
• Casing: Cased
• TXV Installed: Yes
• Suction Connection Size: 7/8 Inch
• Liquid Connection Size: 3/8 Inch
• Width: 21 Inches
• Depth: 21 Inches
• Height: 30 Inches
• Cabinet Width: 21 Inches
• Weight: 51 Pounds
• Voltage: 208, 230V
• Electrical Phases: 1
• Frequency: 60 Hz
• Amperage: 31.1A
• Recommended Breaker Size: 50A
• Maximum Sound Level: 74 dB
• Certifications: AHRI certified, ETL listed, ISO Certified
• Parts Warranty: 10 Limited Years
