GOODMAN CAPFA4226C3 3.5 Ton Upflow/Downflow Cased A Coil - R-32

Product Description

The Goodman CAPFA4226C3 is an evaporator coil for upflow or downflow use. It is made from aluminum and works with R-32 refrigerant. This cased A coil includes a foil-faced insulated cabinet and features a single front access panel. The thermoplastic drain pan is designed for easy maintenance. The coil is ready for vertical installation and has a durable galvanized finish.

• All-aluminum evaporator coil
• Compatible with R-32 refrigerant
• Vertical installation capability

Product Highlights

Ideal for residential and light commercial applications, this coil supports efficient cooling in various configurations.

Product Information

Standard Information

• MPN: CAPFA4226C3
• Product Type: Evaporator Coil

Technical Specifications

• Product Line: CAPFA
• Coil Style: A Coil
• Configuration: Upflow/Downflow
• Refrigerant Type: R-32
• Cooling Capacity: 3.5 Tons
• Cooling BTU: 42000 BTU
• Suction Connection Size: 7/8 Inch
• Liquid Connection Size: 3/8 Inch
• Product Width: 21 Inches
• Product Height: 26 Inches
• Product Depth: 21 Inches
• Product Weight: 35 Pounds
• Certifications: AHRI Certified, ETL Listed, ISO Certified
• Warranty: 10 Year Parts
• Casing: Cased
• Air Flow Direction: Downflow, Upflow
• Line Set Connection Type: Sweat
