Goodman CAPFA3022B6 2.5 Tons Air Conditioner Cased Coil

Product Description

The Goodman CAPFA3022B6 is a 2.5-ton air conditioner cased coil designed for efficient cooling in both upflow and downflow applications. This evaporator coil features all-aluminum construction for enhanced durability and superior heat transfer. It is compatible with both R-22 and R-410A refrigerants, making it adaptable for newer and older systems. Goodman pressure tests each coil twice before shipment to ensure quality and reliability.

• All-aluminum coil for better heat transfer.
• Foil-faced insulation to reduce condensation.
• Galvanized cabinet with a rust-resistant drain pan.

Product Highlights

The Goodman CAPFA3022B6 coil provides efficient performance for residential HVAC systems.

Product Information

Standard Information

• Type: Evaporator Coil
• Application: Upflow/Downflow

Technical Specifications

• Capacity: 2.5 Tons
• Cooling BTU: 30000
• Dimensions: 17.5 inches wide, 21 inches deep, 22 inches high
• Weight: 35 pounds
• Liquid Connection Size: 3/8 inch
• Suction Connection Size: 3/4 inch
• Warranty: 10 Years (with registration)
• Certifications: ETL Listed, AHRI Certified
