Goodman b13400313s Condenser Fan Motor 1/6 Hp 208/230V

Product Description

The Goodman b13400313s is a genuine OEM replacement condenser fan motor designed for single-phase residential HVAC systems. Rated at 1/6 HP and 1075 RPM with a dual-voltage rating of 208/230 volts, this two-speed motor drives the condenser fan blade to move air across the outdoor coil, dissipating heat from the refrigerant circuit. It is an exact OEM replacement, maintaining the electrical and mechanical tolerances specified by Goodman for the original equipment. Licensed HVAC technicians performing condenser section service or motor swap-outs will find this a direct-fit solution requiring no field modifications.

This motor is suited for residential split-system air conditioning and heat pump outdoor units. Confirmed compatible units include the AR18-1, AR18-1D, and AR24-1 series, among other Goodman outdoor condensing units. It is appropriate for retrofit and warranty service work in single-phase residential installations. The two-speed configuration supports variable airflow demands across different operating conditions.

Key Features

• Genuine OEM replacement — matched to original Goodman electrical and mechanical specifications
• 1/6 HP output with 1075 RPM operating speed
• Dual-voltage rated at 208/230 volts for broad residential system compatibility
• Two-speed motor supports variable condenser airflow operation
• Single-phase design for standard residential power supply

Compatibility

Confirmed compatible with Goodman AR18-1, AR18-1D, and AR24-1 outdoor condensing units. Additional compatible models may apply — consult the full fits-models list from the manufacturer for complete compatibility coverage.

Installation Notes

Installation should be performed by a licensed HVAC technician in accordance with applicable local codes and NEC requirements. Disconnect and lock out all power to the outdoor unit at the disconnect box before removing the existing motor or handling any wiring. Verify that the replacement motor shaft rotation direction matches the original before final startup. Secure all wiring connections per the unit wiring diagram and confirm blade clearance before restoring power.

Technical Specifications

• Horsepower: 1/6 HP
• Voltage: 208/230 volts
• Phase: 1-phase
• Speed: 2-speed
• RPM: 1075
• Length: 16.1 inches
• Width: 11.2 inches
• Height: 10.95 inches
• Weight: 9.955 pounds

Standard Information

• Brand: Goodman
• Manufacturer Part Number: b13400313s
