Goodman azv6sa4210 Split Heat Pump 3.5 Ton 16.2 SEER2

Product Description

The GOODMAN azv6sa4210 is a 3.5-ton, single-phase outdoor split heat pump designed for ducted residential and light-commercial applications. It operates on R-32 refrigerant and uses an inverter-driven compressor to deliver a rated cooling capacity of 41,000 BTU/h and a rated heating capacity of 40,000 BTU/h at a 16.2 SEER2 efficiency rating. The unit is side-discharge and non-communicating, making it compatible with standard thermostat wiring. It is manufactured in the United States and classified DOE-compliant for all regions. Licensed HVAC technicians handle installation and commissioning.

This unit is suited for ducted split-system installations in residential single-family, multi-family, and light-commercial settings where a variable-speed, high-efficiency heat pump is required. The inverter compressor allows the unit to modulate capacity across a wide range of ambient conditions, operating in cooling from 0 degrees F to 115 degrees F and in heating from -10 degrees F to 70 degrees F. The side-discharge configuration is appropriate for installations where vertical airflow would conflict with overhead obstructions or equipment clearance requirements.

Key Features

• Inverter-driven compressor with multi-speed motor for variable capacity and quiet operation — rated 70 dBA at high cooling
• 16.2 SEER2 rated efficiency with SEER2 of 17 and HSPF2 of 8.2 under HSVTC test conditions
• R-32 refrigerant with a factory-installed charge of 100 oz and pre-charged line length of 15 feet
• Side-discharge airflow configuration for flexible outdoor placement
• Wide operating range: cooling down to 0 degrees F ambient, heating down to -10 degrees F ambient
• DOE regional compliance for all regions; ISO certified; produced in the United States

Compatibility

Designed as a non-communicating outdoor split heat pump for use with compatible ducted indoor air handler or fan coil units in split-system configurations. Compatible accessory and component references listed in manufacturer data include 130-DK-008, DACA-WB-3, DQ-P-16-100, DSEN-HAQA, KEH3P573567, KPS00601, KPS00602, KPS00603, KPS00604, and KPW5G112.

Installation Notes

Installation must be performed by a licensed HVAC technician in accordance with applicable local codes and the manufacturer installation instructions. Disconnect and lock out all power before making electrical or refrigerant connections. Liquid line connection is 3/8 inch and suction line connection is 7/8 inch O.D.; maximum line set length is 100 feet with a maximum vertical run of 90 feet. R-32 is an A2L mildly flammable refrigerant — follow current ASHRAE 15 and local mechanical code requirements for handling, leak detection, and confined-space installation.

Technical Specifications

• Tonnage: 3.5 ton
• Cooling Capacity (Rated): 41,000 BTU/h
• Heating Capacity (Rated): 40,000 BTU/h
• Heating Capacity (Nominal): 42,000 BTU/h
• SEER2 (HSVTC): 17
• Rated SEER2: 16.2
• HSPF2 (HSVTC): 8.2
• EER2 (HSVTC): 9
• COP47 (HSVTC): 3.3
• Power Voltage: 208/230 volts
• Power Phase: 1-phase
• Power Frequency: 60 Hz
• Rated Load Amps: 25.4 amps
• Min. Circuit Amps: 31.8 amps
• Max Overcurrent Protection: 35 amps
• Compressor Type: Inverter
• Refrigerant Type: R-32
• Factory Refrigerant Charge: 100 oz
• Pre-Charged Line Length: 15 feet
• Max Line Set Length: 100 feet
• Max Vertical Line Set: 90 feet
• Liquid Line Pipe Size: 3/8 inch
• Gas Line Pipe Size: 7/8 inch
• Suction Valve O.D.: 7/8 inch
• Cooling Operation Range: 0 degrees F to 115 degrees F
• Heating Operation Range: -10 degrees F to 70 degrees F
• Sound Pressure (High Cooling): 70 dBA
• Unit Height: 39 inches
• Unit Width: 37 inches
• Unit Depth: 12.625 inches
• Unit Weight: 168 pounds
• Installation Type: Ducted
• Discharge Configuration: Side Discharge
• Communication Type: Non-Communicating
• DOE Regional Compliance: All Regions
• ISO Certified: Yes
• Country of Origin: United States
• Residential Parts Warranty (Registered): 10 years all parts; 10 years compressor unit replacement
• Residential Parts Warranty (Standard): 5 years all parts
• Commercial Parts Warranty: 5 years all parts
• Multi-Family Parts Warranty (Registered): 10 years all parts
• Multi-Family Parts Warranty (Standard): 5 years all parts

Standard Information

• Brand: GOODMAN
• Manufacturer Part Number: azv6sa4210
