Goodman azv6sa2410 Split Heat Pump 2 Ton 16.2 SEER2

Product Description

The GOODMAN azv6sa2410 is a 2-ton, 16.2 SEER2-rated inverter-driven split heat pump outdoor unit designed for ducted residential and multi-family HVAC systems. Operating on R-32 refrigerant, it delivers 23,200 BTU/h of both rated cooling and heating capacity with a side-discharge airflow configuration. The inverter compressor provides variable-speed operation, allowing the unit to modulate output to match load demand rather than cycling on and off at full capacity. Rated electrical supply is 208/230 volts, single phase, 60 Hz, with a minimum circuit ampacity of 16.8 amps and maximum overcurrent protection of 20 amps. Installation and service are performed by licensed HVAC technicians.

The azv6sa2410 is suited for ducted split-system applications in residential and multi-family settings where side-discharge placement is required. Its operating range extends from -10 degrees F to 70 degrees F in heating mode and from 0 degrees F to 115 degrees F in cooling mode, making it viable across a wide range of climates. DOE regional compliance is listed as All Regions. The non-communicating control interface allows pairing with standard thermostat and air handler configurations without a proprietary communicating system. This unit is manufactured in Mexico and carries an active release status under the AZV6SA series.

Key Features

• Inverter compressor with multi-speed motor for variable-capacity operation and improved efficiency
• 16.2 SEER2 seasonal efficiency rating with SEER2 of 18 and HSPF2 of 8.5 under HSVTC conditions
• R-32 refrigerant with factory charge of 74 oz and pre-charged line length of 15 ft
• Side-discharge outdoor unit with compact footprint — 36.625 inches wide, 27.375 inches tall, 13.75 inches deep
• Heating operation range down to -10 degrees F, supporting cold-climate installations
• ISO certified; DOE All-Region compliant

Compatibility

Designed for use in ducted split heat pump systems as part of the Amana AZV6SA series. Non-communicating control type allows pairing with standard, non-proprietary thermostat and air handler controls. Component product references associated with this unit include 130-DK-006, DACA-WB-3, DQ-P-16-100, DSEN-HAQA, KEH3P573598, KPS00501, KPS00502, KPS00503, KPS00504, and KPW5G112 as listed by the manufacturer.

Installation Notes

Installation must be performed by a licensed HVAC technician in accordance with local mechanical codes and the manufacturer installation instructions. Disconnect and lock out all electrical power before servicing the unit. R-32 is a mildly flammable refrigerant classified as A2L — technicians must follow applicable safety protocols and local code requirements when handling, recovering, or charging this refrigerant. Liquid line connection is 3/8 inch and suction valve outside diameter is 3/4 inch, with a gas pipe size of 7/8 inch; confirm line set sizing against the manufacturer specifications before installation.

Technical Specifications

• Tonnage: 2 tons
• Cooling Capacity (Rated): 23,200 BTU/h
• Heating Capacity (Rated): 23,200 BTU/h
• Heating Capacity (Nominal): 24,000 BTU/h
• SEER2 (HSVTC): 18
• Model Efficiency: 16.2 SEER2
• EER2 (HSVTC): 10.2
• HSPF2 (HSVTC): 8.5
• COP47 (HSVTC): 3.3
• Power Voltage: 208/230 volts
• Power Phase: Single phase
• Power Frequency: 60 Hz
• Rated Load Amps: 13.3 A
• Minimum Circuit Amps: 16.8 A
• Max Overcurrent Protection: 20 A
• Compressor Type: Inverter
• Motor Speed Type: Multi-Speed
• Refrigerant Type: R-32
• Factory Refrigerant Charge: 74 oz
• Pre-Charged Line Length: 15 ft
• Standard Line Set Length (Max): 100 ft
• Standard Line Set Length (Vertical): 90 ft
• Liquid Line Size: 3/8 inch
• Gas Pipe Size: 7/8 inch
• Suction Valve OD: 3/4 inch
• Sound Pressure (High, Cooling): 64 dBA
• Cooling Operation Range: 0 degrees F to 115 degrees F
• Heating Operation Range: -10 degrees F to 70 degrees F
• Installation Configuration: Side Discharge
• Unit Type: Outdoor
• Installation Type: Ducted
• Communication Feature Type: Non-Communicating
• DOE Regional Compliance: All Regions
• Unit Width: 36.625 inches
• Unit Height: 27.375 inches
• Unit Depth: 13.75 inches
• Weight: 122 pounds
• Country of Origin: Mexico
• Registered Parts Warranty (Residential): 10 years parts; compressor 10 years parts
• Registered Unit Replacement Warranty (Residential): Compressor 10 years unit replacement
• Standard Parts Warranty (Residential): 5 years parts
• Standard Parts Warranty (Commercial): 5 years parts
• Registered Parts Warranty (Multi-Family): 10 years parts
• ISO Certified: Yes

Standard Information

• Brand: GOODMAN
• Manufacturer Part Number: azv6sa2410
