Goodman axv6ss6010 5 Ton 16.2 SEER2 Inverter Ac Outdoor Unit

Product Description

The Goodman axv6ss6010 is a 5-ton, side-discharge outdoor condensing unit designed for split air conditioning systems. It operates on an inverter-driven compressor, delivering a rated cooling capacity of 53,500 BTU/h at 16.2 SEER2 efficiency. The unit runs on 208/230 volts, single phase, 60 Hz power and uses R-32 refrigerant. Communication-ready design supports integration with the Amana Brand smart thermostat. Built in the United States, this outdoor unit is intended for installation by licensed HVAC technicians in residential and multi-family applications where DOE regional compliance for Southeast and North zones is required.

The axv6ss6010 fits residential and multi-family split-system cooling installations requiring high-efficiency inverter technology in a compact side-discharge configuration. The multi-speed motor and variable-speed inverter compressor allow the unit to modulate output across a wide operating range, from 0 degrees F to 115 degrees F ambient. It is suited for new construction and replacement projects where a high-efficiency, communicating outdoor unit is specified. Compatible accessory references noted in supplier data include 130-DK-008, DACA-WB-3, and KPW5G112.

Key Features

• Inverter-driven compressor with multi-speed fan motor for variable-capacity operation
• 16.2 SEER2 and 9 EER2 efficiency ratings meeting DOE Southeast and North regional compliance
• R-32 refrigerant with factory charge of 118 oz and pre-charged line length of 15 ft
• Side-discharge airflow configuration for installations with restricted overhead clearance
• Communication-ready for use with Amana Brand smart thermostat
• Manufactured in the United States

Compatibility

Designed for use as the outdoor unit in a matched split air conditioning system within the AXV6SS series. Compatible accessory part references provided in product data: 130-DK-008, DACA-WB-3, and KPW5G112. Consult the equipment submittal or system matching guide to confirm indoor unit and air handler compatibility before installation.

Installation Notes

Installation must be performed by a licensed HVAC technician holding an EPA Section 608 certification, as this unit contains R-32 refrigerant, which is an A2L mildly flammable refrigerant requiring adherence to current ASHRAE 15 and local mechanical code requirements. Disconnect and lock out all power at the panel before making any electrical connections. Minimum circuit ampacity is 37.5 amps with a maximum overcurrent protection of 40 amps; verify that existing electrical service meets these requirements before connecting. Standard line set maximum is 100 ft with a maximum vertical separation of 90 ft; do not exceed these limits without consulting the manufacturer installation manual.

Technical Specifications

• Cooling Capacity (Rated): 53,500 BTU/h
• Tonnage: 5 tons
• SEER2: 16.2
• EER2: 9
• Compressor Type: Inverter
• Power Voltage: 208/230 volts
• Power Phase: 1 Ph
• Power Frequency: 60 Hz
• Minimum Circuit Amps: 37.5 A
• Max Overcurrent Protection: 40 A
• Fan/Compressor Drive Input: 30 A
• Refrigerant Type: R-32
• Factory Refrigerant Charge: 118 oz
• Pre-Charged Line Length: 15 ft
• Standard Line Set Max Length: 100 ft
• Standard Line Set Vertical Max: 90 ft
• Liquid Pipe Size: 3/8 inches
• Gas Pipe Size (Suction O.D.): 7/8 inches
• Installation Configuration: Side Discharge
• Cooling Operation Range Min: 0 degrees F
• Cooling Operation Range Max: 115 degrees F
• Motor Speed Type: Multi-Speed
• Sound Pressure (High, Cooling): 71 dBA
• Unit Width: 37 inches
• Unit Height: 39 inches
• Unit Depth: 12.625 inches
• Weight: 174 pounds
• DOE Regional Compliance: Southeast and North
• Country of Origin: United States
• Residential Parts Warranty (Registered): 10 years all parts; 10 years compressor
• Residential Unit Replacement Warranty (Registered): 10 years compressor
• Standard Parts Warranty (Residential): 5 years all parts
• Commercial Parts Warranty: 5 years all parts
• Multi-Family Parts Warranty (Registered): 10 years all parts

Standard Information

• Brand: Goodman
• Manufacturer Part Number: axv6ss6010
