Goodman aszs603610 Split Heat Pump 16.2 SEER2 3 Ton

Product Description

The GOODMAN aszs603610 is a 3-ton, single-phase inverter-driven split heat pump outdoor unit designed for ducted residential and light-commercial HVAC systems. It delivers a rated cooling capacity of 33,600 BTU/h and a rated heating capacity of 34,600 BTU/h, operating at 16.2 SEER2 efficiency with an HSPF2 of 8.2. The inverter-type compressor with multi-speed motor allows the unit to modulate output to match load demand, reducing energy consumption and improving comfort. Refrigerant is R-410A, pre-charged for a 15-foot line set. The unit is configured for side discharge and is manufactured in Thailand.

The aszs603610 is intended for ducted split-system installations in residential, multi-family, and light-commercial applications where regional DOE compliance is required across all climate zones. The unit pairs with compatible Amana brand smart thermostat controls via its integrated communication feature, enabling advanced system coordination. Heating operation is rated down to -10 degrees F ambient, making it suitable for moderate cold-climate applications. It is sized for typical residential loads requiring 3-ton capacity and is installed by licensed HVAC technicians as the outdoor condensing section of a matched split system.

Key Features

• Inverter-type compressor with multi-speed motor for variable-capacity operation
• 16.2 SEER2 cooling efficiency and 8.2 HSPF2 heating efficiency (HSVTC rating)
• Heating operation range from -10 degrees F to 70 degrees F ambient
• Side discharge configuration with compact footprint: 27.375 inches tall, 36.625 inches wide, 13.75 inches deep
• EEV (electronic expansion valve) for precise refrigerant metering
• Communication-ready with Amana brand smart thermostat compatibility
• DOE regional compliance for all climate zones

Compatibility

The aszs603610 is designed for use as the outdoor unit in a matched ducted split heat pump system within the Amana ASZS6 product series. Compatible accessory and component references listed in product data include: 130-DK-006, 130-DK-008, ATST-CWE-BL-A, DACA-WB-3, KEH3P573567, KEH3P573597, KPS00501, KPS00502, KPS00503, KPS00504, KPS00601, KPS00602, KPS00603, KPS00604, KPW5G112, and TXV-FX-KX-3T. Consult Amana system matching guides to confirm the appropriate indoor coil and air handler for this outdoor unit.

Installation Notes

Installation must be performed by a licensed HVAC technician in accordance with local mechanical codes and the manufacturer installation instructions. Disconnect and lock out all electrical power before servicing or connecting refrigerant lines. The unit arrives pre-charged for a 15-foot line set; additional refrigerant charge will be required for longer runs up to the 100-foot maximum standard line set length. Verify that the field-supplied disconnect and overcurrent protection meet the specified minimum circuit ampacity of 23.9 amps and maximum overcurrent protection of 25 amps per NEC requirements.

Technical Specifications

• Tonnage: 3 ton
• Cooling Capacity (Rated): 33,600 BTU/h
• Heating Capacity (Rated): 34,600 BTU/h
• Heating Capacity (Nominal): 36,000 BTU/h
• SEER2 (HSVTC): 16.3
• HSPF2 (HSVTC): 8.2
• EER2 (HSVTC): 8.7
• COP47 (HSVTC): 3
• Power Voltage: 208/230 volts
• Power Phase: 1 phase
• Power Frequency: 60 Hz
• Rated Load Amps: 16.8 amps
• Min. Circuit Amps: 23.9 amps
• Max Overcurrent Protection: 25 amps
• Current Type: AC
• Compressor Type: Inverter
• Compressor Stages: Inverter (variable)
• Motor Speed Type: Multi-Speed
• Expansion Device: EEV
• Refrigerant Type: R-410A
• Factory Refrigerant Charge: 88 oz
• Refrigerant Pre-Charged Line Length: 15 feet
• Standard Line Set Length (Max): 100 feet
• Standard Line Set Length (Vertical Max): 90 feet
• Liquid Line Size: 3/8 inch
• Suction Valve Size (O.D.): 7/8 inch
• Installation Configuration: Side Discharge
• Installation Type: Ducted
• Unit Height: 27.375 inches
• Unit Width: 36.625 inches
• Unit Depth: 13.75 inches
• Unit Weight: 137 pounds
• Sound Pressure (High, Cooling): 68 dBA
• Cooling Operation Range: 0 degrees F to 115 degrees F ambient
• Heating Operation Range: -10 degrees F to 70 degrees F ambient
• DOE Regional Compliance: All regions
• Communication Feature: Yes — Amana brand smart thermostat compatible
• Registered Residential Parts Warranty: 10 years parts; compressor 10 years unit replacement (registration required)
• Standard Residential Parts Warranty: 5 years parts
• Commercial Parts Warranty: 5 years parts
• Country of Origin: Thailand

Standard Information

• Brand: GOODMAN
• Manufacturer Part Number: aszs603610
