Goodman arvt961205dn Gas Furnace 96 Afue 120000 Btu/h

Product Description

The GOODMAN arvt961205dn is a 96 AFUE, two-stage, variable-speed ECM upflow/horizontal gas furnace rated at 120,000 BTU/h high-fire input and 115,320 BTU/h high-fire output. It delivers 84,000 BTU/h at low-fire input and 80,724 BTU/h at low-fire output, allowing the system to match heating demand and reduce short-cycling. The unit runs on 115 volts, single-phase, 60 Hz power and requires a minimum circuit ampacity of 13.8 amps with a maximum overcurrent protection of 20 amps. It is manufactured in the United States and carries ANSI certification and ETL listing. Licensed HVAC technicians install this furnace in residential and light-commercial applications.

This furnace is configured for upflow and horizontal installation, making it suitable for closet, basement, alcove, and attic applications where airflow direction dictates unit orientation. At high fire, the blower delivers 2,130 cubic feet per minute; at low fire, 1,495 cubic feet per minute, using a variable-speed ECM motor rated at 1 metric hp and 1,200 RPM. The unit accommodates up to 5 tons of nominal cooling capacity (60,000 BTU/h), making it compatible with matched split-system cooling coils in that tonnage range. Communication-capable controls allow integration with compatible thermostats and control systems that support communicating protocols.

Key Features

• 96 AFUE two-stage gas valve reduces fuel consumption and improves comfort by running at low fire under partial-load conditions
• Variable-speed ECM blower motor (1 metric hp, 1,200 RPM) provides quiet, efficient airflow at 1,495 to 2,130 cubic feet per minute
• Non-NOx burner configuration with 6 burners meets low-emission requirements where applicable
• Upflow/horizontal installation configuration supports multiple equipment closet and mechanical room layouts
• Communication-ready controls for integration with compatible communicating thermostat systems
• ANSI certified and ETL listed for verified safety and performance compliance
• Manufactured in the United States

Compatibility

Designed for upflow and horizontal residential and light-commercial gas furnace installations with a nominal cooling capacity of up to 5 tons (60,000 BTU/h). Compatible with matched cooling coils and air handlers designed for communicating or conventional thermostat control. Consult the equipment specification sheet for approved coil pairings and accessory compatibility.

Installation Notes

Installation must be performed by a licensed HVAC technician in accordance with local mechanical codes, NFPA 54, and the manufacturer installation instructions. Shut off gas supply and disconnect electrical power before servicing or replacing the unit. Vent diameter options of 2 inches or 3 inches must be verified against the venting design and local code requirements prior to installation. Minimum clearance to combustible materials is 0.1 feet as specified; verify all clearances before final placement.

Technical Specifications

• AFUE: 96
• High-Fire Input Capacity: 120,000 BTU/h
• High-Fire Output Capacity: 115,320 BTU/h
• Low-Fire Input Capacity: 84,000 BTU/h
• Low-Fire Output Capacity: 80,724 BTU/h
• Nominal Cooling Capacity: 60,000 BTU/h (5 tons)
• Power Voltage: 115 volts AC, 1-phase, 60 Hz
• Min. Circuit Amps: 13.8 amps
• Max Overcurrent Protection: 20 amps
• Blower Motor Type: Variable-speed ECM
• Blower Motor Output: 1 metric hp
• Blower Motor RPM: 1,200 RPM
• Air Flow Rate (High Fire): 2,130 ft3/min
• Air Flow Rate (Low Fire): 1,495 ft3/min
• Gas Valve Type: Two Stage
• Number of Burners: 6
• Burner Type: Non-NOx
• Temperature Rise Range (High Fire): 30-60 degrees F
• Temperature Rise Range (Low Fire): 30-60 degrees F
• External Static Pressure (Rated): 0.5 in w.g.
• Installation Configuration: Upflow/Horizontal
• Vent Diameter: 2 inches or 3 inches
• Blower Diameter: 11 inches
• Blower Width: 11 inches
• Unit Width: 24.5 inches
• Unit Height: 34.5 inches
• Unit Depth: 28.875 inches
• Filter Size (Min): 20x25
• Filter Quantity: 1
• Unit Weight: 155 pounds
• Minimum Clearance to Combustibles: 0.1 feet
• Communication Feature: Yes
• ANSI Certified: Yes
• ETL Listed: Yes
• Country of Origin: United States
• Registered Parts Warranty (Residential): All Parts - 10 Years; Heat Exchanger - 20 Years
• Standard Parts Warranty (Residential): All Parts - 5 Years; Heat Exchanger - 20 Years

Standard Information

• Brand: GOODMAN
• Manufacturer Part Number: arvt961205dn
