Goodman ar9s800603bn 60000 Btu/h 80 Afue Gas Furnace

Product Description

The GOODMAN ar9s800603bn is an 80 AFUE single-stage gas furnace built for ducted upflow and horizontal installations. It delivers 60,000 BTU/h of high-fire input capacity with 48,000 BTU/h of output, running on a multi-speed ECM blower motor rated at 1/2 hp. Operating on 115 volts AC at 60 Hz single-phase power, the unit draws a minimum of 8.7 amps with a maximum overcurrent protection of 15 amps. The heat exchanger is a gas-type design rated for a temperature rise range of 20 to 50 degrees F at high fire. Manufactured in the United States and ANSI certified, this furnace is installed by licensed HVAC technicians in residential and light commercial applications requiring reliable single-stage heating with multi-speed airflow control.

This furnace is configured for upflow and horizontal duct systems, making it a fit for installations where the unit sits in a basement, closet, attic, or utility space with horizontal air delivery. With a nominal cooling coil compatibility of 3 tons (36,000 BTU/h nominal cooling capacity), it pairs with a matched evaporator coil for a complete ducted system. The unit width of 17.5 inches fits standard air handler and furnace cabinet openings in typical residential construction. The high-fire airflow rate of 1,260 cubic feet per minute supports proper static pressure and temperature rise across common duct configurations. The Non-NOx burner design meets applicable emissions requirements in regulated markets.

Key Features

• 80 AFUE efficiency rating for ducted residential and light commercial gas heating
• 60,000 BTU/h high-fire input with 48,000 BTU/h output capacity
• Multi-speed ECM blower motor (1/2 hp) with 1,260 CFM high-fire heating airflow
• Single-stage gas valve for straightforward control integration
• Non-NOx burner design meets low-emissions installation requirements
• ANSI certified; manufactured in the United States
• 17.5-inch cabinet width compatible with 3-ton nominal cooling coil pairing

Compatibility

Designed for ducted upflow and horizontal installations with a 3-ton nominal cooling capacity evaporator coil. Compatible system pairings should be confirmed against Amana or Goodman product matching guides using model ar9s800603bn.

Installation Notes

Installation must be performed by a licensed HVAC technician in accordance with local mechanical codes, the International Fuel Gas Code (IFGC), and the manufacturer installation instructions. Shut off gas supply and disconnect electrical power at the disconnect switch before servicing or connecting any components. Verify duct static pressure and temperature rise are within the rated 20 to 50 degrees F range at high fire before commissioning. Do not operate the unit without proper venting installed and verified per applicable code.

Technical Specifications

• AFUE: 80%
• High-Fire Input Capacity: 60,000 BTU/h
• High-Fire Output Capacity: 48,000 BTU/h
• Nominal Cooling Capacity: 36,000 BTU/h (3 tons)
• Temperature Rise Range (High Fire): 20-50 degrees F
• Airflow Rate High Fire Heating: 1,260 CFM
• Gas Valve Type: Single Stage
• Motor Speed Type: Multi-Speed ECM
• Blower Motor Horsepower: 1/2 hp
• Blower Diameter: 10 inches
• Blower Width: 8 inches
• Power Voltage: 115 volts AC
• Power Frequency: 60 Hz
• Power Phase: Single Phase
• Minimum Circuit Amps: 8.7 amps
• Max Overcurrent Protection: 15 amps
• Unit Width: 17.5 inches
• Unit Height: 33.375 inches
• Unit Depth: 28 inches
• Unit Weight: 100 pounds
• Installation Configuration: Upflow/Horizontal
• Heat Exchanger Type: Gas
• Burner Type: Non-NOx
• Unit Type: Indoor Ducted
• Current Type: AC
• ANSI Certified: Yes
• Country of Origin: United States
• Standard Parts Warranty (Residential): All Parts 5 Years; Heat Exchanger 20 Years
• Registered Parts Warranty (Residential): All Parts 10 Years; Heat Exchanger 20 Years

Standard Information

• Brand: GOODMAN
• Manufacturer Part Number: ar9s800603bn
