Goodman ar9s800603ax 60K Btu 80 Afue Gas Furnace 14 in

Product Description

The Goodman ar9s800603ax is an 80 AFUE single-stage gas furnace rated at 60,000 BTU/h high-fire input with a multi-speed ECM blower motor. It is designed for ducted, indoor installations in upflow or horizontal configurations. The unit delivers 48,000 BTU/h output capacity and moves up to 1,221 cubic feet per minute of airflow on high heat. Licensed HVAC technicians install this furnace in residential and light-commercial applications where space, budget, and efficiency requirements call for an 80 percent AFUE gas system. Low NOx burner technology reduces nitrogen oxide emissions, and ANSI certification confirms the unit meets established safety and performance standards.

The ar9s800603ax is suited for upflow or horizontal duct installations in residential and multi-family buildings. Its 14-inch cabinet width fits standard alcove, closet, and platform installations where space is limited. With a nominal cooling coil matchup of 36,000 BTU/h (3 tons), it pairs with a compatible evaporator coil for split-system air conditioning. This furnace is a practical choice for new construction and replacement projects where an 80 AFUE unit meets local energy code minimums.

Key Features

• 80 AFUE efficiency with single-stage gas valve for straightforward capacity control
• Multi-speed ECM blower motor with high-fire airflow of 1,221 ft3/min
• Low NOx burner meets low-emissions requirements in applicable jurisdictions
• Upflow and horizontal installation configurations supported in one cabinet
• 14-inch cabinet width fits space-constrained closet and alcove installations
• ANSI certified for safety and performance compliance
• Nominal 3-ton cooling matchup (36,000 BTU/h) for split-system integration

Compatibility

Designed for ducted residential and multi-family gas furnace installations in upflow or horizontal orientation. Compatible with 3-ton nominal evaporator coil assemblies for split-system cooling. Consult Goodman product documentation to confirm compatible coil and air handler pairings before installation.

Installation Notes

Installation must be performed by a licensed HVAC technician in accordance with the International Fuel Gas Code (IFGC), local mechanical codes, and the manufacturer installation manual. Shut off gas supply and disconnect electrical power before beginning any service or installation work. The unit requires a 115-volt, single-phase, 60 Hz power supply with a maximum overcurrent protection of 15 amps and a minimum circuit ampacity of 8.7 amps. Verify vent and combustion air requirements are met before startup, and confirm all gas connections are leak-tested prior to energizing the system.

Technical Specifications

• AFUE: 80%
• High-Fire Input Capacity: 60,000 BTU/h
• High-Fire Output Capacity: 48,000 BTU/h
• Nominal Cooling Capacity: 36,000 BTU/h (3 tons)
• Gas Valve Type: Single Stage
• Blower Motor Type: Multi-Speed ECM
• Blower Motor Horsepower: 1/2 hp
• High-Fire Airflow: 1,221 ft3/min
• Burner Type: Low NOx
• Power Voltage: 115 volts AC
• Power Phase: Single Phase
• Power Frequency: 60 Hz
• Minimum Circuit Amps: 8.7 amps
• Max Overcurrent Protection: 15 amps
• Temperature Rise Range (High Fire): 20-50 degrees F
• Installation Configuration: Upflow / Horizontal
• Unit Width: 14 inches
• Unit Height: 33-3/8 inches
• Unit Depth: 28 inches
• Blower Diameter: 10 inches
• Blower Width: 6 inches
• Unit Weight: 90 pounds
• Heat Exchanger Type: Gas
• Current Type: AC
• Unit Type: Indoor Ducted
• ANSI Certified: Yes
• Registered Residential Warranty: Heat Exchanger - 20 Years Parts; All Parts - 10 Years Parts
• Standard Residential Warranty: Heat Exchanger - 20 Years Parts; All Parts - 5 Years Parts

Standard Information

• Brand: Goodman
• Manufacturer Part Number: ar9s800603ax
