Goodman 4mxt36avju9 36000 Btu Quad-zone Mini Split

Product Description

The GOODMAN 4mxt36avju9 is a 36,000 BTU/h configurable quad-zone mini split outdoor unit from the Aurora MXT Series, designed for both heating and cooling applications across a wide range of ambient temperatures. This inverter-driven compressor unit uses R32 refrigerant and is rated for heating operation from -13 degrees F up to 60 degrees F, with cooling operation from 14 degrees F up to 115 degrees F. The standard drain pan design supports drainage in extreme cold-weather conditions to reduce ice build-up. Licensed HVAC technicians install this unit as part of a multi-zone ductless split system.

The Aurora MXT Series is engineered for residential and light commercial applications where multi-zone comfort control is required. This quad-zone outdoor unit delivers 114% of rated heating capacity at 5 degrees F and maintains 100% cooling capacity at 104 degrees F, making it suitable for installation across all climate regions of the country. The MXT line is available in 2-zone, 3-zone, 4-zone, and 5-zone configurations. An optional drain pan heater accessory (KEH063A4EA) is available for the 4MXT model for installations in severe cold climates.

Key Features

• 36,000 BTU/h quad-zone outdoor unit with inverter compressor for variable-speed operation
• Heating range from -13 degrees F to 60 degrees F with 114% rated heating capacity at 5 degrees F
• Cooling range from 14 degrees F to 115 degrees F with 100% cooling capacity at 104 degrees F
• R32 refrigerant for improved efficiency and lower global warming potential compared to R410A
• Standard drain pan with enhanced drainage geometry to reduce ice accumulation in extreme cold
• Compatible with optional drain pan heater accessory KEH063A4EA for severe cold-climate installs
• Cold Climate Energy Star rated MXT series

Compatibility

Part of the Aurora MXT Series multi-zone ductless split system platform, compatible with Daikin Cloud WiFi Adaptor for remote comfort control via tablet or smartphone. Optional heated drain pan upgrade available via accessory KEH063A4EA. The MXTH variant provides a factory heated drain pan for installations requiring that feature.

Installation Notes

Installation must be performed by a licensed HVAC technician holding EPA Section 608 certification due to the use of R32 refrigerant, which is classified as mildly flammable (A2L). Disconnect and lock out all electrical power to the system before connecting or disconnecting refrigerant lines or electrical wiring. Follow all local mechanical and electrical codes, including NEC requirements for disconnect sizing and equipment grounding. Do not mix refrigerants or reuse recovered refrigerant without proper reclamation procedures.

Technical Specifications

• Capacity: 36,000 BTU/h
• Zone Configuration: Quad-Zone (4-Zone)
• Refrigerant: R32
• Compressor Type: Inverter
• Heating Ambient Range: -13 degrees F to 60 degrees F
• Cooling Ambient Range: 14 degrees F to 115 degrees F
• Rated Heating Capacity at 5 degrees F: 114%
• Rated Cooling Capacity at 104 degrees F: 100%
• Drain Pan Type: Standard
• Certification: Energy Star Cold Climate

Standard Information

• Brand: GOODMAN
• Manufacturer Part Number: 4mxt36avju9
