Goodman 0270D01791S Uncased Upflow/Downflow Evaporator Coil - 3 Ton

Product Description

The Goodman 0270D01791S is a reliable indoor evaporator coil suitable for both upflow and downflow configurations. This evaporator coil is designed specifically for use with split system air conditioners and heat pumps. Made from all-aluminum materials, it includes features such as aluminum tubing, fins, and end plates. The coil is compatible with R-410A refrigerant, enabling efficient cooling and heating performance.

• Supports R-410A refrigerant for effective cooling
• Equipped with a thermoplastic drain pan including secondary drain connections
• Optimized for both upflow and downflow installations

Product Highlights

This evaporator coil is engineered to meet the needs of air conditioning and heating applications, providing efficient performance and adaptability.

Product Information

Standard Information

• Product Type: Evaporator Coil
• Configuration: Upflow/Downflow

Technical Specifications

• Air Handler/Coil Tonnage: 3 Ton(s)
• Primary Refrigerant: R-410A
• Refrigerant Metering Device: Orifice
• Number of Rows: 3
• High Output Cool: 35000 BTU
• Liquid Line Size (OD): 3/8 inches
• Suction Line Size (OD): 7/8 inches
• Dimensions: 16 3/8 inches (Width) x 21 inches (Height) x 20 inches (Depth)
• Product Weight: 30 lbs
