GOODMAN 0270D00614S Goodman Cased Evaporator Coil 0270D00614S

Product Description

The Goodman Cased Evaporator Coil, model 0270D00614S, is built for use with split system air conditioners and heat pumps. This coil features a design that allows for either upflow or downflow setup, making it versatile for different installation scenarios. The cabinet sports an architectural gray finish, adding a professional touch to the overall look.

• Compatible with R-410A and R-22 refrigerants.
• Rust-proof thermoplastic drain pan.
• Equipped with a check flowrater expansion device.

Product Highlights

This evaporator coil ensures efficient cooling in residential and commercial settings. Its reliable design supports larger systems and is equipped for straightforward maintenance.

Product Information

Standard Information

• Product Type: Evaporator Coil
• Configuration: Downflow / Upflow

Technical Specifications

• Primary Refrigerant: R-410A
• Secondary Refrigerant: R-22
• Air Handler / Coil Tonnage: 5 Ton(s)
• High Output Cool: 60000 BTU
• Number of Rows: 4
• Liquid Line Size (OD): 3/8 Inches
• Suction Line Size (OD): 7/8 Inches
• Width: 24.5 Inches
• Depth: 21 Inches
• Height: 30 Inches
• Product Weight: 76 lbs
• Orifice Size: 0.093 Inches
• Plenum Opening Width: 23.5 Inches
• ENERGY STAR Capable: Yes
