Goodman 0202G00581S Condenser Coil Assembly

Product Description

The Goodman 0202G00581S is a condenser coil assembly designed for use in Goodman packaged heat pump systems. This OEM replacement coil is constructed with aluminum tubing and serves as the heat exchange component responsible for rejecting heat from the refrigerant to the outdoor air during cooling mode and absorbing heat during heating mode. It is a direct-fit assembly intended for installation by licensed HVAC technicians performing coil replacement or system refurbishment on compatible Goodman packaged units.

This condenser coil assembly is matched to the Goodman GPH1360M41CA packaged heat pump unit. Packaged heat pump systems are commonly installed in residential and light commercial applications where a single outdoor cabinet houses all system components. Coil replacement is typically required following refrigerant leaks, physical damage, or corrosion that compromises system efficiency or refrigerant containment.

Key Features

• OEM Goodman replacement condenser coil assembly for direct fitment
• Aluminum tubing construction for corrosion resistance and heat transfer efficiency
• Designed for packaged heat pump system application
• Factory-assembled coil configuration for simplified field installation

Compatibility

Designed as a direct OEM replacement condenser coil assembly for the Goodman GPH1360M41CA packaged heat pump unit.

Installation Notes

Installation must be performed by a certified HVAC technician holding the appropriate EPA Section 608 refrigerant handling certification. The system must be recovered of all refrigerant and electrical power must be disconnected at the disconnect box before coil removal begins. Coil connections require brazing by a qualified technician; follow applicable mechanical codes for refrigerant piping practices. After installation, the system must be evacuated and leak-tested before recharging with the refrigerant type specified on the unit nameplate.

Technical Specifications

• Material: Aluminum tubing
• UPC: 193031122251

Standard Information

• Brand: Goodman
• Manufacturer Part Number: 0202G00581S
