GOODACES PPV3585 Blower Motor 1/3HP 1075 RPM

Product Description

The GOODACES PPV3585 blower motor is designed for various HVAC applications. This three-speed motor features an electronically reversible design for simple installation and energy efficiency. It operates effectively in environments up to forty degrees Celsius and is UL/CSA approved. With Class B insulation, this motor provides durability and reliability. It includes an auto protector and incorporates Rheem holes in the shell for straightforward mounting. The motor comes with a thirty-six lead length for easy wiring.

• Three-speed blower motor for versatile use
• Electronically reversible for easy installation
• Energy-efficient operation

Product Highlights

The GOODACES PPV3585 is efficient and reliable. It fits many HVAC configurations.

Product Information

Standard Information

• Type: Blower Motor
• Brand: GOODACES

Technical Specifications

• HP: 1/3
• Volts: 115
• Rated Amps: 5.5-3.0-2.0
• Bearings: Sleeve
• RPM/SPD: 1075/2
• Shaft Size: 1/2 X 4
• Capacitor (MFD) 370V: 7.5
• BM DIM: 4.36
• Amperage Rating: 5.5 A
• Body Diameter: 5-1/2 Inch
• Enclosure Type: Open Air Over
• Frame: 48
• Frequency Rating: 60 Hz, 1 Phase
• Mounting Type: Through Bolt
• Number of Speeds: 3
• Rotation Type: CCW/CW
