GOLIATH 96143 AG-4200E Condensate Overflow Sensor

Product Description

The GOLIATH AG-4200E is a condensate overflow sensor designed for effective condensate management systems. This device is compatible with Goliath, Goliath Furnace, Goliath Value Series, and Titan drain pans. The sensor incorporates advanced water sensing technology paired with a drain port and an optional drain plug. An adjustable height mount is included for easy installation. The product is equipped with vibration isolators to minimize false triggers.

• Electronic switch can operate in normally open or normally closed configurations.
• Includes a LED indicator for quick visual confirmation of water detection.
• Comes with fourteen vibration isolators to enhance performance.

Product Highlights

The GOLIATH AG-4200E provides reliable monitoring of condensate overflow, ensuring system reliability and preventing overflow issues.

Product Information

Standard Information

• Brand: GOLIATH
• MPN: 96143

Technical Specifications

• Type: Electronic
• Switch Type: Electronic
• Voltage: 24 VAC
• Maximum Amps Running: 5
• Connection Size: three-fourths inch
• Cord Length: six feet of control wire
• Wire Gauge: 18 AWG
• Mounting Type: Secondary
• Size: five inches by four and one-half inches by three inches
• Height: two point eight seven five inches
• Length: four point six two five inches
• Width: four point three seven five inches
• Weight: one
• Composition: Polystyrene
• Cycle/Hertz: 60 Hz
• Phase: Single
• Plenum Rated: No
• Prop 65: No
• Approvals: UL Listed; UL Recognized
