Gm Lighting LTHE-20-DIM-24 compact LED electronic dimmable 20W 24VDC class 2

Product Description

The GM Lighting LTHE-20-DIM-24 is a 20W 24VDC Class 2 compact LED electronic dimmable power supply. Designed for hardwire installations, it operates with a 120V/60Hz input and is compatible with conventional TRIAC wall dimmers, providing flicker-free dimming for LED lighting applications. Its compact design allows for under cabinet mounting, making it suitable for various lighting projects. This power supply features auto-reset functionality and is ETL listed.

• Compact design allows for under cabinet mounting
• Dimmable with standard TRIAC dimmers
• Class 2 power supply with auto reset functionality

Product Highlights

Compact 20W 24VDC Class 2 LED power supply, dimmable with TRIAC dimmers, ideal for under cabinet lighting.

Product Information

Standard Information

• Brand: GM LIGHTING
• Manufacturer Part Number: LTHE-20-DIM-24
• Country of Origin: China

Technical Specifications

• Wattage: 20W
• Output Current: 0.83 A
• Output Voltage: 24VDC
• Efficiency: >84%
• Input Voltage: 120V/60Hz
• Class: Class 2
• Dimmable: Yes (with standard TRIAC dimmers)
• Auto Reset: Yes
• Certifications: ETL listed
• Technology: LED
• Driver Type: Constant Voltage
• Material: Plastic
• Series: LTHE
• Suitable For Use With: LED lighting
• Finish: White
• Location Rating: Dry Rated
