Global GMQ-3-2/10 Time Delay In-Line Fuse

Product Description

The Global GMQ-3-2/10 is a time-delay in-line fuse for circuit protection. Designed with a cylindrical ceramic body, it includes wire terminals for easy connections. This fuse has a rated amperage of three point two amps and supports a voltage of up to three hundred VAC. It is ideal for protecting in-line lighting ballasts and has an interrupt rating of ten kA, which is essential for safety in electrical circuits.

• Time delay functionality for reliable circuit protection.
• Cylindrical body style for easy mounting.
• Suitable for panel mounting with wire terminals.

Product Highlights

The Global GMQ series of fuses effectively prevents overfusing, which enhances the reliability of your electrical systems.

Product Information

Standard Information

• Brand: Global
• Manufacturer: Bussmann Fuses

Technical Specifications

• Fuse Type: In-Line Fuse
• Speed: Time Delay
• Amperage Rating: 3.2 A
• Voltage Rating: 300 VAC
• Interrupt Rating: 10 kA
• Material: Ceramic
• Mounting Type: Panel
• Body Style: Cylindrical
• Element: Single
• Terminal Type: Wire
• Standard & Approvals: CE Certified, CSA Class 1422-01, File 53787, UL File E19180, RoHS Compliant
• Body Size: five eighths inch diameter x two and one quarter inches length
• Application: In-line Lighting Ballast Protection
• Diameter: 0.63 inches
