Product Description
The Glasfloss ZLP20244 Z-Line Series pleated filters offer improved performance for many applications. These filters feature fibers that do not absorb moisture and will not support microbial growth. The Glasfloss Z-Line Series SB, ZL and HV filters achieve a MERV 10 rating per the ANSI/ASHRAE 52.2 Test Standard.
- Heavy-Duty Moisture Resistant Construction
- Galvanized Expanded Metal Backing
- Fibers do not absorb moisture and will not support microbial growth
Product Highlights
Glasfloss ZLP20244 filters provide excellent performance and value for a wide range of applications. They are ideal for residential, commercial, and industrial HVAC systems.
Product Information
Standard Information
-
Brand: GLASFLOSS
-
Manufacturer Part Number: ZLP20244
-
Country of Origin: USA
Technical Specifications
-
Brand: Glasfloss
-
Width: 24
-
Height: 20
-
Length: 4
-
Frame Type: Die-Cut Beverage Board
-
Filter Type: Pleated
-
MERV Rating: 10
-
Removes Smoke: No
-
Country of Origin: USA
-
Filter Efficiency: 40% to 85%
-
Removes Fine Dust: Yes
-
Pleats per Linear Feet: 9
-
Filter Rating (Microns): 1.0 to 10.0
-
Nominal Filter Width in Inches: 20
-
Nominal Filter Height in Inches: 24
-
Nominal Filter Thickness in Inches: 4
-
Nominal Filter Size in Inches (W x H x D): 20 x 24 x 4
-
Actual Size: 19-3/8 x 23-3/8 x 3-3/4 in
-
Temperature Rating: 180 deg F
-
Media Material: Synthetic Fiber
-
Flow Rate: 500 fpm
-
Resistance: 0.25 Inch WG
-
Application: Residential, Commercial, Industrial
-
Applicable Standard: ANSI/ASHRAE 52.2, USGBC, NAFA, HardI, UL
-
Depth: 4 in
-
Final Resistance: 1 in WG
-
Initial Resistance: 0.18 in wg
-
Series: Z-Line ZL
