Gibraltar MAS-0200 Support Screw Jack 40000 Lb

Product Description

The GIBRALTAR MAS-0200 is a support screw jack rated for a minimum load capacity of 40,000 pounds. It is designed to provide rigid, adjustable vertical support in structural, mechanical, and industrial applications. The unit features a 2.75-inch base diameter and an adjustable height range spanning 2.125 inches to 3.125 inches, allowing field technicians and tradespeople to fine-tune mounting height to fit the installation. At 2.6 pounds, the MAS-0200 is compact and easy to handle. It is typically installed by millwrights, pipefitters, structural mechanics, or general contractors working on equipment support and leveling tasks.

The MAS-0200 is suited for use as a leveling or support element under machinery bases, structural frames, pipe supports, and similar load-bearing assemblies. Its screw-jack design allows incremental height adjustment without additional shimming. The compact footprint makes it appropriate for installations where space around the support point is limited. It is used in both light industrial and commercial construction settings wherever a heavy-duty, adjustable point support is required.

Key Features

• Minimum load capacity of 40,000 pounds for heavy-duty structural support
• Adjustable height range from 2.125 inches to 3.125 inches for precise leveling
• 2.75-inch base diameter provides stable footprint under load
• Screw-jack design allows tool-assisted height adjustment without shimming
• Compact, single-unit package at 2.6 pounds for easy field handling

Compatibility

Designed as an OEM-style replacement or direct-fit support component for machinery bases, structural frames, and equipment pads requiring a heavy-duty adjustable screw jack with a 2.75-inch base diameter and a height range of 2.125 inches to 3.125 inches.

Installation Notes

Installation is typically performed by a licensed millwright, pipefitter, or structural mechanic. Before installing or adjusting support jacks under live equipment, confirm all loads are safely de-energized or relieved and that the structure is properly braced. Use the appropriate wrench or spanner to turn the screw jack to the required height within the rated adjustment range. Do not exceed the 40,000-pound minimum rated capacity, and verify that the mounting surface can distribute the point load appropriately.
