Gibraltar LP1-A4-G Studded Pivotal Leveling Mount 2000 Lb

Product Description

The GIBRALTAR LP1-A4-G is a studded pivotal leveling mount designed to provide stable, adjustable support for machinery, equipment frames, and fabricated assemblies. The pivotal pad design allows the mount to self-align to uneven floor surfaces, compensating for minor angular variations without compromising load distribution. Built with a steel pad and steel stud, this mount carries a rated load capacity of 2,000 lb and measures 5.25 inches in overall length with a 2 inch base diameter. Millwrights, pipefitters, and industrial maintenance technicians install this type of mount during equipment positioning and leveling operations.

This leveling mount is suited for use in industrial and commercial settings where heavy equipment requires precise, stable footing on concrete or steel floor surfaces. Common applications include machine bases, compressor skids, pump frames, and structural support stands. The 3/8-16 bolt thread allows integration with standard threaded mounting holes found on a wide range of fabricated and OEM equipment frames. At 0.42 pounds, the mount is compact enough for dense machine bases where clearance is limited.

Key Features

• 2,000 lb rated load capacity for heavy equipment support
• Pivotal pad design self-aligns to uneven or slightly angled mounting surfaces
• Steel pad and steel stud construction for durability in industrial environments
• 3/8-16 threaded stud compatible with standard machine mounting holes
• 2 inch base diameter provides stable footprint in compact mounting areas
• 5.25 inch overall length allows leveling adjustment across a usable height range

Compatibility

Designed as an OEM-style replacement or new-installation leveling mount for industrial machinery, equipment skids, and fabricated frames that accept a 3/8-16 threaded stud mount.

Installation Notes

Installation is typically performed by millwrights or maintenance technicians using standard hand tools. Before installing or adjusting, ensure the equipment is de-energized and properly supported to prevent unintended movement. Thread the stud into the equipment base to the appropriate engagement depth before setting final height and tightening the locknut if applicable. Verify that the total load across all mount points does not exceed the rated capacity per mount.
