Gibraltar GLH-586-G Type E Gear Lever Arm M12x1.75

Product Description

The GIBRALTAR GLH-586-G is a Type E gear lever arm fitted with a cylindrical phenolic knob, designed for use in manual actuation applications on industrial equipment, machinery, and control assemblies. The arm features an M12x1.75 threaded stem for secure mounting, a stainless steel shaft measuring 0.55 inches in diameter, and a phenolic knob 1.02 inches in diameter. The handle runs 6.7 inches in total length, providing sufficient leverage for operator adjustments. The stainless steel shaft offers corrosion resistance in demanding environments. This component is installed by maintenance technicians and machine builders working on equipment requiring adjustable gear or positioning levers.

The GLH-586-G suits industrial and commercial machinery applications where a hand-operated lever arm is needed for gear selection, clamping, or positioning functions. The M12x1.75 stem threads directly into compatible tapped holes in machine frames, fixtures, or gear housings. The cylindrical phenolic knob provides a firm, ergonomic grip without requiring additional tooling for routine operator adjustments. Thread length is 0.63 inches and knob length is 2.76 inches, making this arm appropriate for installations with moderate clearance requirements around the mounting surface.

Key Features

• M12x1.75 threaded stem for direct installation into standard metric tapped holes
• Stainless steel shaft at 0.55 inches diameter for corrosion resistance and durability
• Phenolic cylindrical knob at 1.02 inches diameter for a secure, tool-free grip
• 6.7 inches handle length delivers mechanical advantage for manual gear or position adjustments
• 0.63 inches thread engagement length suits standard mounting depths
• Lightweight construction at 0.14 pounds minimizes added load on machinery assemblies

Compatibility

Designed as an OEM-style replacement or direct-fit lever arm for industrial equipment and machinery accepting M12x1.75 threaded gear lever assemblies with Type E configuration.

Installation Notes

Installation is performed by maintenance technicians or machine builders. Power down and de-energize all equipment before removing or installing lever arm components. Thread the M12x1.75 stem into the tapped hole by hand first to confirm proper thread engagement before applying a wrench to avoid cross-threading. Follow applicable machinery safety standards and the equipment manufacturer guidelines when replacing or retrofitting lever arm assemblies.
