Gibraltar BSNYLC58-G Studded Pivotal Leveling Mount

Product Description

The GIBRALTAR BSNYLC58-G is a studded pivotal leveling mount rated for 10,000 lb load capacity, designed for industrial and commercial equipment leveling applications. The mount features a 5-inch base diameter with a nylon pad that protects flooring surfaces while allowing slight angular adjustment to compensate for uneven floors. The stainless steel stud provides corrosion resistance in demanding environments. At 10.25 inches in length and 1.4 pounds, this leveling foot is built for heavy-duty stationary equipment installations requiring stable, adjustable footing.

This leveling mount is suited for use in manufacturing facilities, machine shops, food processing environments, and commercial settings where heavy equipment must be leveled on concrete or finished floors. The pivotal base accommodates minor floor irregularities without compromising load stability. The 5/8-11 bolt thread size is compatible with standard heavy-duty machine bases and equipment frames. Installation is typically performed by millwrights, maintenance technicians, or equipment installers handling industrial machinery leveling and alignment.

Key Features

• 10,000 lb load capacity supports heavy industrial and commercial equipment
• Nylon pad protects floor surfaces and reduces vibration transfer
• Stainless steel stud offers corrosion resistance for demanding environments
• Pivotal base design accommodates minor angular floor irregularities
• 5/8-11 bolt thread size fits standard heavy-duty machine bases
• 5-inch base diameter distributes load across a wide footprint

Compatibility

Designed as a direct-fit leveling mount for heavy-duty stationary equipment, machine bases, and industrial frames with 5/8-11 threaded mounting provisions.

Installation Notes

Installation is typically performed by millwrights or maintenance technicians using standard hand tools and a level. Ensure the equipment is fully de-energized and supported safely before installing or adjusting leveling mounts. Do not exceed the rated 10,000 lb load capacity. Thread the stainless steel stud into the equipment base and adjust the mount height before locking the machine in its final leveled position.
